Net engine power is with standard equipment including air
cleaner, exhaust system, alternator, and cooling fan, at standard
conditions per SAE J1349 and DIN 70 020, using No. 2-D fuel at
35 API gravity. No derating is required up to 5,000-ft. (1525 m)
altitude for the 444J and 544J, and up to 10,000-ft. (3050 m)
altitude for the 624J. Gross power is without cooling fan. Specifications and design subject to change without notice. Wherever applicable, specifications are in accordance with ISO standards.
Except where otherwise noted, these specifications are based on a unit with all standard equipment, ROPS cab, full fuel tank, and
175-lb. (79 kg) operator; a 444J unit with 17.5 R 25 tires; and 544J and 624J units with 20.5 R 25 tires.
DKAJULDRP Litho in U.S.A. (05-01)
444J 544J 624J Engine
● ● ● Meets EPA Tier II non-road emissions regulations
● ● ● Wet sleeve cylinder liners
● ● ● Electronically controlled fuel system
● ● ● Automatic derating when system temperatures
exceeded
● ● ● Monitor-selected high-altitude compensation
● ● ● Underhood muffler with large exhaust stack
● ● ● Underhood dual-element air cleaner with restriction
sensor in cab monitor
● ● ● Underhood, pre-screened air intake
● ● ● 10-micron primary fuel filter/water separator
● ● ● 2-micron final fuel filter
● ● ● Heavy-duty steel fuel tank guard
● ● ● 500-hour full-flow spin-on oil filter
● ● ● Polyvee drive belt with automatic tensioner
▲ ▲ Ether start aid (required for cold starting down to
–13°F [–25°C])
▲ ▲ Intake air heater (required for cold starting down to
0°F [–18°C])
▲ ▲ ▲ 110-volt engine coolant heater (required for cold
starting below –13°F [–25°C])
▲ ▲ ▲ Centrifugal engine air pre-cleaner
▲ ▲ ▲ Chrome exhaust stack
▲ ▲ ▲ Environmentally friendly engine oil drain
▲ ▲ ▲ Special-application trash screens, axle seal guards, etc.*
Cooling
● ● ● Heavy-duty trash-resistant high-ambient cooling
package
● ● ● Two-side access to all coolers
● ● ● Cooling system isolated from engine compartment
● ● ● Proportionally controlled (cool-on-demand), hydrau-
lically driven, swing-out fan
● ● ● Intercooler (air/air – 6.5 fins per in.)
● ● ● Transmission oil cooler (oil/air – 6.5 fins per in.)
● ● ● Hydraulic oil cooler (oil/air – 6.5 fins per in.)
● ● ● Engine radiator (7.5 fins per in.)
● ● ● Integral engine oil cooler
● ● ● Coolant recovery tank
● ● ● Fan guard
▲ ▲ ▲ Axle coolers (6.5 fins per in.)
▲ ▲ ▲ Reversing fan drive — auto control with manual
override
▲ ▲ ▲ Harsh-environment coolers for corrosive environments
Powertrain
● ● ● ZF torque-converter powershift transmission — 4F/3R
● ● ● Electronically controlled, adaptive, load- and speed-
dependent shift modulation
● ● ● Clutch calibration engageable from cab monitor
● ● ● Clutch cut-off — thresholds setable from switch pad
● ● ● Auto-shift/manual-shift modes
● ● ● Gear kickdown button in hydraulic-control lever
● ● ● 1,000-hour transmission filter
● ● ● Integral transmission sight gauge/fill tube
● ● ● Spring-applied, hydraulically released, oil-cooled,
multi-disc park brake
● ● ● Lube-for-life U-joints
● ● ● Heavy-duty inboard planetary final drives
● ● ● Hydraulically actuated, inboard, carrier-mounted,
pressure-oil-cooled, self-adjusting, multi-disc brakes
● ● ● Top axle housing fill and dipstick port
● ● ● Front axle with hydraulic locking differential
▲ ▲ ▲ Front and rear axles with hydraulic locking differentials
▲ ▲ ▲ Front and rear axle with open differential*
▲ ▲ ▲ Limited slip differentials*
▲ ▲ ▲ Front-axle disconnect
▲ ▲ ▲ Remote-axle breathers
Hydraulic System
● ● ● Pressure-compensated load-sensing hydraulic system
● ● ● In-cab adjustable automatic bucket positioner/fork
positioner
● ● ● In-cab adjustable automatic boom height kickout control
444J 544J 624J Hydraulic System (continued)
● ● ● In-cab adjustable automatic boom return-to-carry
control
● ● ● Reservoir sight gauge
● ● ● Spin-on hydraulic filters, vertical mounting
● ● ● Hydraulic lever lockout
● ● ● Two-function hydraulic valve with single-lever control
▲ ▲ ▲ Two-function hydraulic valve with two-lever fingertip
controls and adjustable wristrest
▲ ▲ ▲ Three-function hydraulic valve with single-lever con-
trol and auxiliary lever for third function
▲ ▲ ▲ Three-function hydraulic valve with two-lever finger-
tip controls, adjustable wristrest, and auxiliary lever
for third function
▲ ▲ ▲ Four-function hydraulic valve, with dual single-lever
controls
▲ ▲ ▲ Hydraulic conversion kits, two-to-three- and three-
to-four-function valves
▲ ▲ ▲ Ride control, automatic type
▲ ▲ ▲ Hydraulic control system for quick-coupler locking pins
Electrical
● ● ● 24-volt electrical system
● ● ● Solid-state electrical power distribution system
● ● ● High-capacity batteries (2), 12 volt with 950 CCA,
200-min. rated reserve
● ● ● Master electrical disconnect switch
● ● ● Alternator, high capacity, 80 amps and 24 volts
▲ ▲ ▲ Alternator trash covers
● ● ● Lights (conform to SAE 99): Driving with guards /
Turn signals and flashers / Stop and taillights
▲ ▲ ▲ LED heavy-duty taillights and turn signals
● ● ▲ Work lights, front (2) and rear (2)
● ● ● Horn, with push button in center of steering wheel
(conforms to SAE J994, J1446)
● ● ● Reverse warning alarm (conforms to SAE J994, J1446)
● ● ● Computerized multifunction monitor
● ● ● Audible and visual warnings: Amber caution / Red
stop / Analog gauges: Engine coolant temperature,
transmission oil temperature, fuel level, hydraulic
oil temperature, engine oil pressure / Digital instru-
ments: Engine rpm, odometer, transmission gear
indicator, speedometer, hour meter / Operator warn-
ing lights: Check engine, engine oil pressure, engine
air filter restriction, battery voltage, transmission filter
restriction, brake pressure, hydraulic oil filter, fasten
seat belt, transmission fault, hydraulic oil temperature
● ● ● Indicator lights: Park brake / Ride control / Turn sig-
nals and warning flashers / Coupler pin disconnect /
Engine preheater / Secondary steering / Work lights
● ● ● Built-in diagnostics: Fault code retrieval
▲ ▲ ▲ AM/FM/WB stereo radio
▲ ▲ ▲ AM/FM/WB stereo radio with cassette
▲ ▲ ▲ AM/FM/WB stereo radio with CD
▲ ▲ ▲ 5-amp, 12-volt convertor with one power plug
▲ ▲ ▲ 10-amp, 12-volt convertor with two power plugs
● ● ● Cab wired for rotating beacon
▲ ▲ ▲ Electrical corrosion-prevention package
Operator’s Station
● ● ● Canopy (conforms to SAE J1040 APR88): ROPS/FOPS /
Multiplane isolation mounted for noise/vibration
reduction / Optional canopy rear window glass, for
noise reduction
▲ ▲ ▲ Cab (conforms to SAE J1040 ARP88): ROPS/FOPS /
Heater/defroster / Multiplane isolation mounted for
noise/vibration reduction / Front and rear windshield
washers and intermittent wipers / Tinted safety glass
▲ ▲ ▲ Canopy rear window
▲ ▲ ▲ Air conditioning
● ● ● Seat belt, 3 in. (76 mm), with retractor
● ● ● Seat, deluxe vinyl covered with deep foam, high
back, air suspension, adjustable for weight-height,
fore-aft position, backrest tilt, and armrest angle
444J 544J 624J Operator’s Station (continued)
▲ ▲ ▲ Seat, deluxe cloth covered with deep foam, high
back, air suspension, adjustable for weight-height,
fore-aft position, backrest tilt, and armrest angle
● ● ● Seat backrest extension
● ● ● Cup holder, personal cooler holder
▲ ▲ ▲ Sun visor for cab
● ● ● Storage compartment for operator’s manual and
other items
● ● ● Rubber floormat
● ● ● Tilt steering column
● ● ● Steering wheel, textured with spinner knob
● ● ● Rearview mirrors, outside (2) and inside (1) (conform
to SAE J985)
● ● ● Handholds and steps, ergonomically located and slip
resistant (conform to SAE J185)
Loader Linkage
● ● ● Loader boom service locking bar (conforms to
SAE J38)
● ● ● Powerllel linkage for versatility, visibility, and paral-
lel-lift
▲ ▲ ▲ Z-bar loader linkage
▲ ▲ ▲ High-lift Z-bar loader linkage
Buckets and Attachments
▲ ▲ ▲ Full line of Deere pin-on and hook-on buckets with
selection of bolt-on cutting edges and teeth-seg-
mented bolt-on cutting edges*
▲ ▲ ▲ Quick-coupler which accepts Deere and JRB
attachments
▲ ▲ ▲ Hydraulic control system for quick-coupler locking
pins, includes all controls in the cab, lines, and valves
▲ ▲ ▲ Construction utility forks for couplers
Tires
▲ 17.5-25, 12 PR L2
▲ 17.5-25, 12 PR L3
● 17.5 R 25, Goodyear GP-2B Radial
▲ 17.5 R 25, Michelin XTLA Radial
▲ 17.5 R 25, Michelin XHA Radial
▲ ▲ ▲ 20.5-25, 12 PR L2
▲ ▲ 20.5-25, 16 PR L3
▲ ▲ 20.5 R 25, Michelin XHA Radial
▲ ▲ ▲ 20.5 R 25, Michelin XTLA Radial
● ● 20.5 R 25, Goodyear GP-2B Radial
▲ ▲ ▲ 600/65 R 25 Goodyear GP-3D Radial
▲ 23.1-26, 10 PR LS-2 Logger
▲ 28L-26, 14 PR LS-2 Logger
▲ Single-piece rims
● ● ● Multi-piece rims
▲ ▲ ▲ Less wheels and tires
▲ ▲ ▲ 8-degree rear axle stops for extra-large tires and chains
Other
▲ ▲ ▲ Sound-suppression package
● ● ● Fenders, front
▲ ▲ ▲ Fenders, full-coverage front
▲ ▲ ▲ Fenders, full-coverage front and rear
▲ ▲ ▲ Close-mounted steps
● ● ● Articulation locking bar (conforms to SAE J276)
● ● ● Vandal protection, includes lockable engine enclosure
and fuel fill
● ● ● Counterweight, built-in
● ● ● Front and rear tie-down points
● ● ● Drawbar, with locking pin
▲ ▲ ▲ Extended rear bumper with drawbar
▲ ▲ ▲ Transmission side frame guards
▲ ▲ ▲ Bottom guards, front frame and transmission
▲ ▲ ▲ Lift hooks
▲ ▲ ▲ Fire extinguisher
▲ ▲ ▲ License plate bracket
▲ ▲ ▲ Secondary steering
▲ ▲ ▲ Loadrite TM weighing system
444J / 544J / 624J POWERLLEL LOADERS
Key: ● Standard equipment ▲ Optional equipment *See your John Deere dealer for further information.
