About the speaker impedance
The required speaker impedance of the front speakers does differ depending on whether
both the FRONT SPEAKERS 1 and FRONT SPEAKERS 2 terminals are used or
only one of them is used. CAUTION:
When connecting speakers, use
speakers with the same
SPEAKER IMPEDANCE
indicated by the speaker
terminals.
CASE 1 When you connect only one set of front speakers
CASE 2 When you connect two sets of front speakers
Use front speakers with 4 — 16 ohm impedance.
Front
Speaker
1
Front
Speaker
1
Front
Speaker
1
Front
Speaker
1
Front
Speaker
2
Front
Speaker
2
Use front speakers with 8 — 16 ohm impedance.
