11

Using the freezer

Switches and indicators

A) On/off indicator

green

B) On/off switch
C) Thermostat button (for higher

temperatures)
D) Temperature display
E) Thermostat button (for lower

temperatures)
F) Alarm indicator

red

G) ACOUSTIC alarm OFF switch

(see "Control and information system")

H) QUICK FREEZE indicator

yellow

J) QUICK FREEZE pushbutton switch

Basket Storage

Frozen food should be stored in the freezer baskets

and the second compartment used for storage or fast

freezing of fresh food.

Operation and use

Installation

Insert the plug into the socket. Press the on/off switch

of the freezing compartment. The green on/off

indicator will light continuously and the current

temperature value will flash.

The flashing of the red alarm indicator and the

acoustic alarm will warn you that the internal

temperature is not yet sufficient for the conservation

of food. To switch off the acoustic alarm and the

temperature display flashing, press button "G". Do not

put any food in the freezer until the internal

temperature reaches -18 C or the red alarm indicator

goes out.

Adjusting the temperature

Temperature controls

Temperature can be regulated with the use of the "+"

(higher) and "-" (lower) buttons.
These buttons are interlinked with the temperature

display.

Press either "+" or "-" to switch the temperature

display from CURRENT temperature

(continuous lighting ) to DESIRED temperature

(flashing).

If neither button is pressed again, the

temperature display will shortly (within approx. 5

seconds) return to CURRENT temperature.

DESIRED temperature:

It is the temperature to be achieved in the freezing

compartment.

CURRENT temperature:

It is the actual temperature of the freezing

compartment as shown on the temperature display.

The CURRENT temperature is shown by a

continuous light.

Temperature display

The temperature display is able to show various

information:

Under normal operating conditions it displays the

actual temperature (CURRENT temperature) of the

freezer.

At the time of setting the temperature, the freshly set

temperature (DESIRED temperature) will flash.

QUICK FREEZE on/off switch

The quick freeze function ("FROSTMATIC") is used

to achieve the quick freezing of fresh food and to

prevent the already frozen goods from undesirable

warming up. You can turn on the quick freeze

function by pressing the quick freeze on/off switch.

The yellow indicator will light up.
You can manually turn off the quick freeze function

any time by pressing the quick freeze on/off switch

again. The yellow indicator will go out. If not

switched off manually, the quick freeze function will

be automatically switched off 48 hours later. The

yellow indicator will go out.

Temperature problem

Once the temperature of the freezing

compartment rises above -12 C the red alarm

indicator will light up and an acoustic alarm will be

heard.
Possible causes of such temperature rise:

door opened too frequently or left open too long
large volume of hot foot stored in the freezing

compartment
product defect.

You can stop the acoustic alarm by pressing the "Acoustic

alarm off switch". Once the temperature of the freezing

compartment reduces to a displayable value, the red

alarm indicator and the acoustic alarm will automatically

stop.
