SB-SMRT-4-2/8W3V3 INSTR_SKU# 011288
Page 5• JL Audio, Inc 2009
All specifications are subject to change without notice. “JL Audio®” and the JL Audio logo, “Stealthbox” and the Stealthbox logo are registered
trademarks of JL Audio, Inc. “Ahead of the Curve” and its respective logo is a trademark of JL Audio, Inc.
JLA-SKU# 011288 03-26-2009 • Printed in USA • ©2008 JL Audio, Inc. • U.S. PATENTS: #5,734,734 #5,949,898 #6,118,884 #6,229,902 #6,243,479
#6,294,959 #6,501,844 #6,496,590 #6,441,685 #5,687,247 #6,219,431 #6,625,292 #D472,891 #D480,709 Other U.S. & Foreign patents pending.
For more detailed information please visit us online at www.jlaudio.com.
(954) 443-1100 w w w. j l a u d i o . c o m
1 0 3 6 9 N O R T H C O M M E R C E P A R K W A Y • M I R A M A R , F L O R I D A • 3 3 0 2 5 • U S A
I n C l u d e d H a R d W a R e
6) 1/4” Split Lock Washer 5) 1/4” Flat Washer
3) 1/4-20 Hex Nut 3) 1/4-20 x 1” Hex Head Bolt
1) 1/4-20 Speed Clip 1) 1/4-20 x 12” All Threaded Rod
5) 3/8” Flat Washer 2) 3/8-16 x 1” Hex Head Bolt
3) 3/8” Split Lock Washer 1) 3/8-16 x 1 1/2” Hex Head Bolt
2) 3/8-16 Hex Nut 4) Custom Brackets
s P e C I F I C a t I o n s
Enclosure Type: Acoustic Suspension (sealed)
Driver Type: 8W3v3-4
Nominal Impedance: 4 Ohms
Continuous Power Handling: 250 Watts
P o W e R R e C o m m e n d a t I o n
JL Audio recommends using a high quality amplifier such as the JL Audio 250/1v2.
The diagram below shows the recommended crossover, infrasonic filter and equalizer settings for the 250/1v2
when being used to power your Stealthbox
® .
The JL Audio 250/1v2 is a very versatile audio component. Please consult the owner’s manual for even more
detailed information about installing and tuning this amplifier.
m I d / H I G H F R e q u e n C Y d R I V e R F I t m e n t
A variety of JL Audio coaxial and component systems will fit in the factory speaker locations of you vehicle.
Front Speaker Size / Location: 6.0”- Front Doors
Fits JL Audio Models: C2-650, C2-650x
To change the OEM front speakers requires extensive
modification and, the use of spacers/adaptors.
