JVC GC-QX3 - Manual (Page 5)

EN
5
QUICK START
Power outlet
Connect the Camera to a Power
Outlet. (
੬ pg. 20)
1 Open the connector cover on the rear of the
camera.
2 Connect the DC cord to the DC input
connector.
3 Connect the DC cord to the DC input
connector on the AC adapter.
4 Connect the power cord to a power outlet.
•The power lamp lights.
Insert the Memory card. (
੬ pg. 22)
1 Open the Memory card cover.
•Slide the knob to the open position.
2 Insert the Memory card.
•Insert the card so that the contact surface is
facing up and the notch on the card is on the
right.
3 Close the Memory card cover.
•Slide the knob to the close position.
Power lamp
Power cord
AC adapter
(AA-V37)
DC input connector
Memory card (3.3V type)
Memory card cover
DC cord
Knob
