GETTING STARTED 16
EN
MasterPage: Left
1
Set the Power Switch to “REC” while pressing
down the Lock Button located on the switch.
2
Make sure the LCD monitor is closed and
locked. Pull out the viewfinder fully and adjust it
manually for best viewability.
3
Turn the Dioptre Adjustment Control until the
indications in the viewfinder are clearly focused.
CAUTION:
When retracting the viewfinder, take care not to
pinch your fingers.
1
Set the Power Switch
to “REC” or “PLAY” while
pressing down the Lock
Button located on the
switch.
2
Open the LCD monitor
fully. ( ੬ pg. 18)
● To adjust the brightness of
the viewfinder, pull out the
viewfinder fully and set
“PRIORITY” to “FINDER”
( ੬
pg. 23 , 25) .
3
Press MENU. The
Menu Screen appears.
If you are in Playback mode, please proceed to
step 5.
4
Press or to select “DISPLAY”, and
press SET or . The DISPLAY Menu appears.
5
Press or to select “BRIGHT”, and press
SET or . The Menu Screen closes and the
brightness control MENU appears.
6
Press or until the appropriate
brightness is reached and press SET or .
7
Press MENU. The Menu screen closes.
To attach the camcorder
to a tripod, align the
direction stud and screw
to the mounting socket
and stud hole on the
camcorder. Then tighten
the screw clockwise.
● Some tripods are not
equipped with studs.
Viewfinder Adjustment
Dioptre Adjustment Control
Example:
Brightness Adjustment Of The
Display
Tripod Mounting
BRIGHT
MENU
