40
FM tuner (IHF)
Tuning Range: 87.50 MHz to 108.00 MHz
Usable Sensitivity: Monaural: 12.8 dBf (1.95 µV/75
Ω
)
50 dB Quieting Sensitivity: Monaural: 21.3 dBf (3.2 µV/75
Ω
)
Stereo: 41.3 dBf (31.5 µV/75
Ω
)
Signal-to-Noise Ratio (IHF-A weighted): Monaural: 78 dB at 85 dBf
Stereo: 73 dB at 85 dBf
Total Harmonic Distortion: Monaural: 0.4% at 1 kHz
Stereo: 0.6% at 1 kHz
Stereo Separation at REC OUT: 35 dB at 1 kHz
Alternate Channel Selectivity: 45 dB: (±400 kHz)
Frequency Response: 30 Hz to 15 kHz: (+0.5 dB, –3 dB)
AM tuner
Tuning Range: 522 kHz to 1 629 kHz
Usable Sensitivity: Loop antenna 400 µV/m
Signal-to-Noise Ratio 50 dB (100 mV/m)
General
Power Requirements: AC 240V , 50 Hz
Power Consumption: 200 W (at operation)
5 W (in standby mode)
Dimensions (W x H x D): 435 mm x 146.5 mm x 425.5 mm
(17
3 / 16 in. x 5 13 / 16 in. x 16 13 / 16 in.)
Mass: 9.6 kg (21.2 lbs)
Designs & specifications are subject to change without notice.
