John Lewis JLUCFRW6001 - Manual (Page 8)

8
Door Reversal
If required the door can be reversed, hinged from the left,
opening from the right.
To reverse the bottom hinge assembly proceed as follows:
Disconnect the appliance from the electricity supply.
Tilt the appliance backwards, resting the top edge of the
appliance on a stool or something similar.
Unscrew the 2 adjustable feet. Unscrew the 3 screws
holding the lower door bracket. transfer the lower door
hinge pin to the alternative position as shown in the top
drawing. Unscrew the single screw at the bottom left
hand side and retain . Replace the lower door bracket on
the bottom left hand side but do not fully tighten the 3
screws.
Remove the fridge door by gently pulling downwards and
store to avoid damage.
Unscrew the top door hinge pin of the refrigerator then
screw it back on the other side.As shown in the second
drawing.
Replace the fridge door on the upper door hinge pin.
Insert the lower door hinge pin into the door and tighten
all screws.
Re-fix the retained screw to the bottom right hand side
and replace the 2 adjustable feet.
Lift the fridge back onto its feet and check it is set level
and the door seal meets the fridge all around the door.
Transfer the handle to the opposite side and place the
plastic covering inserts, (supplied in the plastic bag of this
instruction book) into the holes set free.
Reconnect the fridge to the electricity supply.
