JVC GR-D850 GR-D870 - Manual (Page 13)

EN
13
Getting Started
ENGLISH
Controls
Control Lever (
੬ 8)
: Left/Rewind (3) (੬ 22)/Quick Review
[QUICK REVIEW] (
੬ 19)
: Right/Fast-Forward (5) (੬ 22)/
LED Light [LIGHT] (
੬ 34)
: Up/Play/Pause (U/9) (੬ 21)/
Manual Focus [FOCUS] (
੬ 35)
: Down/Stop (8) (੬ 21)/Backlight
Compensation [ ] (
੬ 36)/Spot Exposure
(
੬ 36)
Press down : SET
Menu Button [MENU] (
੬ 21)
Auto Button [AUTO] (
੬ 20)
Data Battery Button [DATA] (
੬ 17)
MEMORY/VIDEO Switch (
੬ 13)
Recording Start/Stop Button (
੬ 19)
Zoom Lever [T/W] (
੬ 21)/
Speaker Volume Control [VOL. +, –] (
੬ 21)
Power Switch [REC, OFF, PLAY]
Lock Button
Cassette Open/Eject Switch [OPEN/
EJECT] (
੬ 18)
Battery Release Button [BATT.] (
੬ 16)
16:9 Wide Screen Button [16:9] (
੬ 18)/
Blank Search [BLANK] (
੬ 22)/
Index Button [INDEX] (
੬ 24)
Snapshot Button [SNAPSHOT] (
੬ 21, 34)/
Live Slow Button [SLOW]
(
੬ 34)
Connectors
USB (Universal Serial Bus)
Connector (
੬ 42)
Digital Video Connector [DV IN/OUT]
(i.LINK*) (
੬ 41, 42)
* i.LINK refers to the IEEE1394-1995
industry specifi cation and extensions
thereof. The logo is used for products
compliant with the i.LINK standard.
The connectors are located beneath the cover.
Audio/Video Output Connector [AV] (
੬ 40)
DC Input Connector [DC] (
੬ 16)
Indicator
R POWER/CHARGE Lamp (
੬ 16)
Other parts
S LCD Monitor (
੬ 12)
T Shoulder Strap Eyelet (
੬ 9)
U Grip Strap ( ੬ 10)
V Camera Sensor
(Be careful not to cover this area, a sensor
necessary for shooting is built-in here.)
W Stereo Microphone
X Lens
Y Speaker (
੬ 21)
Z LED Light (
੬ 34)
(Be careful not to cover this area during
shooting.)
a Cassette Holder Cover (
੬ 18)
b Stud Hole (
੬ 10)
c Tripod Mounting Socket (
੬ 10)
d Battery Pack Mount (
੬ 16)
e Connector Cover
f Memory Card Slot
g Card Cover
Power Switch Position
Set the Power Switch while
pressing down the lock button.
REC:
• To perform recording on the tape.
•
To perform recording in the
memory card.
OFF:
To switch off the camcorder.
PLAY:
• To play back a recording on the tape.
•
To display a still image stored
in the memory card or to transfer a still
image stored in the memory card or PC.
MEMORY/VIDEO
Switch Position
VIDEO:
To record on a tape or play back a tape.
MEMORY:
To record in a memory card or access data
stored in a memory card.
