7 - 4
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
[MAIN UNIT]
REF ORDER
DESCRIPTION M.
H/V
NO. NO. LOCATION
R267 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 12.9/18.6
R268 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 12.3/21.2
R269 7030005290 S.RES ERJ2GEJ 682 X (6.8 k) T 23.2/36.1
R272 7030004970 S.RES ERJ2GEJ 470 X (47) B 90.4/7.1
R273 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 95.4/8.9
R274 7030005120 S.RES ERJ2GEJ 102 X (1 k) T 93/6.2
R275 7030004980 S.RES ERJ2GEJ 101 X (100) T 95.9/7.5
R276 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 8.4/22.2
R277 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 9.3/22.2
R279 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 24.3/11.8
R280 7510001730 S.TMR ERTJOEP 473J B 57.1/7.3
R281 7030010080 S.RES ERJ2RHD 104 X (100 k) B 56.2/5.4
R282 7030005110 S.RES ERJ2GEJ 224 X (220 k) T 68.1/25.2
R283 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 35.8/16.9
R284 7030008290 S.RES ERJ2GEJ 183 X (18 k) B 66.2/26
R285 7030005070 S.RES ERJ2GEJ 683 X (68 k) B 66.5/27.2
R286 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 64/27.4
R287 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 28.6/40.9
R288 7030005720 S.RES ERJ2GEJ 563 X (56 k) B 29.8/39
R289 7030005310 S.RES ERJ2GEJ 124 X (120 k) B 30.1/41.4
R290 7030005240 S.RES ERJ2GEJ 473 X (47 k) B 28.9/40.9
R291 7030005000 S.RES ERJ2GEJ 471 X (470) B 41.8/23.9
R292 7030005240 S.RES ERJ2GEJ 473 X (47 k) T 39.2/19.3
R293 7030005700 S.RES ERJ2GEJ 274 X (270 k) T 38.3/19.3
R294 7030005310 S.RES ERJ2GEJ 124 X (120 k) B 94.4/8.9
R295 7030005310 S.RES ERJ2GEJ 124 X (120 k) B 95.5/10.1
R296 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 95.5/11.9
R297 7030007340 S.RES ERJ2GEJ 153 X (15 k) B 95.5/11
R298 7030005160 S.RES ERJ2GEJ 105 X (1 M) T 46.1/24.3
R301 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 104.6/36.8
R302 7030010040 S.RES ERJ2GEJ-JPW B 56.5/40.2
R303 7030010040 S.RES ERJ2GEJ-JPW B 45.3/36.8
R304 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 78.3/36.6
R305 7030007300 S.RES ERJ2GEJ 332 X (3.3 k) B 80.6/37.9
R306 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 19.2/10.1
R307 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 9.4/8.7
R308 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 37.5/26.3
R309 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 33.7/14.4
R310 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 32.4/15.3
R312 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 45/13.4
R313 7030007340 S.RES ERJ2GEJ 153 X (15 k) T 6.8/33.9
R314 7030007340 S.RES ERJ2GEJ 153 X (15 k) T 9/31.8
R315 7030007340 S.RES ERJ2GEJ 153 X (15 k) T 10.5/31.8
R316 7030005160 S.RES ERJ2GEJ 105 X (1 M) B 6.5/38.2
R317 7030005160 S.RES ERJ2GEJ 105 X (1 M) B 12.2/12.5
R318 7030005160 S.RES ERJ2GEJ 105 X (1 M) B 5.3/35.9
R319 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 11.9/17.2
R320 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 9.4/9.6
R328 7510001730 S.TMR ERTJOEP 473J T 55.3/37.2
R329 7030005060 S.RES ERJ2GEJ 333 X (33 k) T 55.6/36
R330 7030005290 S.RES ERJ2GEJ 682 X (6.8 k) T 55.8/34.8
R331 7030007340 S.RES ERJ2GEJ 153 X (15 k) T 47.1/16.5
R332 7030005010 S.RES ERJ2GEJ 681 X (680) B 52.5/27.1
R333 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 17.1/31.8
R335 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 58.3/8
R336 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 34.4/4.7
R337 7030007340 S.RES ERJ2GEJ 153 X (15 k) B 52.1/28.4
R338 7030007340 S.RES ERJ2GEJ 153 X (15 k) B 51.6/27.1
R339 7030003860 S.RES ERJ3GE JPW V B 65.1/12.5
R340 7030005000 S.RES ERJ2GEJ 471 X (470) B 88.6/9.6
R341 7030005530 S.RES ERJ2GEJ 100 X (10) B 88.8/10.8
R342 7030005000 S.RES ERJ2GEJ 471 X (470) B 90/10.1
R343 7030005120 S.RES ERJ2GEJ 102 X (1 k) B 62.7/21.8
C1 4030017420
S.CER ECJ0EC1H470J B 51.8/29.6
C2 4030017620 S.CER ECJ0EC1H100C T 57.9/24
C3 4030017430 S.CER ECJ0EC1H101J T 57.9/20.8
C4 4030016930 S.CER ECJ0EB1A104K B 55.1/23.2
C5 4030016930 S.CER ECJ0EB1A104K B 52.8/20.7
C7 4030017460 S.CER ECJ0EB1E102K B 53.7/20.7
C8 4030017650 S.CER ECJ0EC1H270J B 62.7/20
C9 4030017420 S.CER ECJ0EC1H470J B 62.7/17.5
C10 4030016930 S.CER ECJ0EB1A104K B 52.8/13.7
C11 4030017420 S.CER ECJ0EC1H470J B 51.4/14.3
C12 4030017420 S.CER ECJ0EC1H470J B 49.9/16.6
C13 4030017420 S.CER ECJ0EC1H470J B 51.3/17
C14 4030006900 S.CER C1608 JB 1H 103K-T B 65.4/19.6
C16 4550000550 S.TAN TEESVA 1V 224M8R B 67.4/24.4
C17 4030017460 S.CER ECJ0EB1E102K B 63/14.7
C18 4030017460 S.CER ECJ0EB1E102K B 66.9/13.7
C19 4550000510 S.TAN TEESVA 1V 473M8R B 67.4/22.3
C21 4030017420 S.CER ECJ0EC1H470J B 64/8.5
C22 4030017420 S.CER ECJ0EC1H470J T 63.6/13.6
C23 4030017460 S.CER ECJ0EB1E102K B 66.9/18.6
C24 4030017580 S.CER ECJ0EC1H060C [H] T 66.2/10.8
C24 4030017590 S.CER ECJ0EC1H070C [L] T 66.2/10.8
C25 4030017590 S.CER ECJ0EC1H070C [H] T 67.3/9.8
C25 4030017620 S.CER ECJ0EC1H100C [L] T 67.3/9.8
C26 4030017350 S.CER ECJ0EC1H020B [H] T 67.7/8.6
C26 4030017570 S.CER ECJ0EC1H040B [L] T 67.7/8.6
C27 4030017630 S.CER ECJ0EC1H120J T 70.4/10.8
C28 4030017360 S.CER ECJ0EC1H030B [H] T 71.3/9.8
[MAIN UNIT]
REF ORDER
DESCRIPTION M.
H/V
NO. NO. LOCATION
C28 4030017380 S.CER ECJ0EC1H050B [L] T 71.3/9.8
C29 4030017570 S.CER ECJ0EC1H040B [H] T 72.1/8.6
C29 4030017600 S.CER ECJ0EC1H080C [L] T 72.1/8.6
C30 4030016930 S.CER ECJ0EB1A104K T 73.4/13.4
C31 4030017460 S.CER ECJ0EB1E102K T 71.4/13.4
C32 4030017460 S.CER ECJ0EB1E102K T 71.4/19.9
C33 4030016930 S.CER ECJ0EB1A104K T 73.4/19.9
C34 4030017640 S.CER ECJ0EC1H150J T 70.4/17.3
C35 4030017570 S.CER ECJ0EC1H040B [H] T 71.3/16.3
C35 4030017600 S.CER ECJ0EC1H080C [L] T 71.3/16.3
C36 4030017590 S.CER ECJ0EC1H070C [H] T 71.7/15.1
C36 4030017630 S.CER ECJ0EC1H120J [L] T 71.7/15.1
C37 4030017360 S.CER ECJ0EC1H030B [H] T 67.7/15.1
C37 4030017380 S.CER ECJ0EC1H050B [L] T 67.7/15.1
C38 4030017610 S.CER ECJ0EC1H090C [H] T 67.3/16.3
C38 4030017630 S.CER ECJ0EC1H120J [L] T 67.3/16.3
C39 4030017390 S.CER ECJ0EC1H180J [L] T 66.2/17.3
C39 4030017580 S.CER ECJ0EC1H060C [H] T 66.2/17.3
C39 4030017630 S.CER ECJ0EC1H120J T 66.2/17.3
C40 4030016930 S.CER ECJ0EB1A104K T 74.5/26.1
C41 4030017460 S.CER ECJ0EB1E102K B 72.3/26.6
C42 4030017640 S.CER ECJ0EC1H150J T 70.4/23.7
C43 4030017580 S.CER ECJ0EC1H060C T 71.2/22.7
C44 4030017610 S.CER ECJ0EC1H090C T 71.7/21.5
C45 4030017560 S.CER ECJ0EC1H2R5B T 67.7/21.5
C46 4030017340 S.CER ECJ0EC1H010B T 69.9/25.2
C47 4030017340 S.CER ECJ0EC1H010B T 69.5/26.4
C48 4030017620 S.CER ECJ0EC1H100C [H] T 67.3/22.7
C48 4030017650 S.CER ECJ0EC1H270J [L] T 67.3/22.7
C49 4030017660 S.CER ECJ0EC1H330J T 66/23.7
C50 4030017420 S.CER ECJ0EC1H470J B 66/20.7
C51 4030017420 S.CER ECJ0EC1H470J B 67.4/27
C52 4030016930 S.CER ECJ0EB1A104K B 65.6/27.2
C53 4030017530 S.CER ECJ0EC1H0R5B T 74.2/11.3
C54 4030017530 S.CER ECJ0EC1H0R5B T 74.4/17.3
C55 4030017530 S.CER ECJ0EC1H0R5B T 74.4/19.9
C56 4030017460 S.CER ECJ0EB1E102K B 73.7/20.2
C57 4030017460 S.CER ECJ0EB1E102K B 67.7/12.6
C58 4550006250 S.TAN TEESVA 1A 106M8R B 79.6/18.6
C59 4030016790 S.CER ECJ0EB1C103K B 81.1/23.2
C60 4030017460 S.CER ECJ0EB1E102K T 77.7/18.2
C61 4030017730 S.CER ECJ0EB1E471K T 76.2/20.6
C62 4030017580 S.CER ECJ0EC1H060C T 80/18
C63 4030017460 S.CER ECJ0EB1E102K T 81.3/21.6
C65 4030017460 S.CER ECJ0EB1E102K T 80/24.4
C66 4030017380 S.CER ECJ0EC1H050B T 77.6/14
C67 4030017460 S.CER ECJ0EB1E102K T 79.9/13.5
C68 4030017460 S.CER ECJ0EB1E102K T 81.1/15.5
C69 4030017620 S.CER ECJ0EC1H100C B 82.7/13.3
C71 4030017460 S.CER ECJ0EB1E102K B 85.9/16.3
C73 4030017380 S.CER ECJ0EC1H050B B 88.1/13.5
C75 4030017570 S.CER ECJ0EC1H040B B 91.7/18
C76 4030017420 S.CER ECJ0EC1H470J B 89.7/17
C77 4030017460 S.CER ECJ0EB1E102K B 88.8/16.2
C78 4030017460 S.CER ECJ0EB1E102K B 86.8/18.5
C79 4030017380 S.CER ECJ0EC1H050B B 93.5/17.3
C100 4030017420 S.CER ECJ0EC1H470J T 48.5/18.7
C101 4030017420 S.CER ECJ0EC1H470J T 57.9/14.6
C113 4030017730 S.CER ECJ0EB1E471K T 56.6/7.1
C118 4030017460 S.CER ECJ0EB1E102K T 105.5/26.9
C119 4030017510 S.CER ECJ0EC1H680J B 105.9/27.4
C120 4030017590 S.CER ECJ0EC1H070C B 106/24.2
C121 4030017590 S.CER ECJ0EC1H070C [H] B 104.8/23.8
C121 4030017600 S.CER ECJ0EC1H080C [L] B 104.8/23.8
C122 4030017400 S.CER ECJ0EC1H220J B 103.2/20.8
C123 4030017460 S.CER ECJ0EB1E102K B 100/19.9
C124 4030017460 S.CER ECJ0EB1E102K T 103.1/21.1
C125 4030017560 S.CER ECJ0EC1H2R5B B 106.1/20.5
C126 4030017400 S.CER ECJ0EC1H220J B 103.2/17.2
C127 4030017590 S.CER ECJ0EC1H070C [H] B 104.8/20.2
C127 4030017600 S.CER ECJ0EC1H080C [L] B 104.8/20.2
C128 4030017590 S.CER ECJ0EC1H070C B 105.3/16.9
C129 4030017460 S.CER ECJ0EB1E102K B 103/13.8
C130 4030017420 S.CER ECJ0EC1H470J B 103/14.7
C131 4030017420 S.CER ECJ0EC1H470J B 104.9/11.4
C132 4030017460 S.CER ECJ0EB1E102K T 104.7/11.4
C133 4030017460 S.CER ECJ0EB1E102K T 100.6/8.1
C134 4030016930 S.CER ECJ0EB1A104K T 104/13.6
C135 4030016930 S.CER ECJ0EB1A104K T 104.3/14.8
C136 4030017460 S.CER ECJ0EB1E102K T 102.8/11
C137 4030017420 S.CER ECJ0EC1H470J B 105.3/9.5
C138 4030017460 S.CER ECJ0EB1E102K B 105.7/8.3
C139 4030017460 S.CER ECJ0EB1E102K B 100.3/7.3
C141 4030017350 S.CER ECJ0EC1H020B [L] B 103/12.9
C141 4030017550 S.CER ECJ0EC1H1R5B [H] B 103/12.9
C142 4030017630 S.CER ECJ0EC1H120J B 103/11.3
C143 4030017620 S.CER ECJ0EC1H100C [H] B 99.3/8.9
C143 4030017630 S.CER ECJ0EC1H120J [L] B 99.3/8.9
C144 4030017520 S.CER ECJ0EC1H0R3B B 100.7/8.4
C145 4030017460 S.CER ECJ0EB1E102K B 99.6/11.3
C146 4030017460 S.CER ECJ0EB1E102K T 100.9/11.7
C147 4030017340 S.CER ECJ0EC1H010B B 96.3/8.9
C148 4030017380 S.CER ECJ0EC1H050B B 96/7.7
C151 4030017550 S.CER ECJ0EC1H1R5B T 79/21.4
[L]=Low band [H]=High band
