Main unit – Icom IC-F3061S User Manual
Page 57
7 - 3
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
[MAIN UNIT]
REF
ORDER
DESCRIPTION
M.
H/V
NO.
NO.
LOCATION
R61
7030005090 S.RES ERJ2GEJ 104 X (100 k)
B 100.3/18.7
R62
7030005050 S.RES ERJ2GEJ 103 X (10 k)
B 100.9/20.8
R63
7030005080 S.RES ERJ2GEJ 823 X (82 k)
B 105.5/15.7
R64
7030005240 S.RES ERJ2GEJ 473 X (47 k)
B 106.7/14.8
R65
7030004980 S.RES ERJ2GEJ 101 X (100)
B
103/15.6
R66
7030005530 S.RES ERJ2GEJ 100 X (10)
B 106.1/11.1
R68
7030008400 S.RES ERJ2GEJ 182 X (1.8 k)
T
102.1/8.3
R69
7030005170 S.RES ERJ2GEJ 474 X (470 k)
T 102.1/10.1
R70
7030005110 S.RES ERJ2GEJ 224 X (220 k)
T
102.1/9.2
R71
7030005050 S.RES ERJ2GEJ 103 X (10 k)
T 104.9/13.6
R72
7030005530 S.RES ERJ2GEJ 100 X (10)
T 103.1/12.2
R73
7030004970 S.RES ERJ2GEJ 470 X (47)
B
103.4/7.3
R74
7030005120 S.RES ERJ2GEJ 102 X (1 k)
[L] B 103.2/10.3
R74
7030007290 S.RES ERJ2GEJ 222 X (2.2 k)
[H] B 103.2/10.3
R75
7030005090 S.RES ERJ2GEJ 104 X (100 k)
B 101.2/10.1
R76
7030005090 S.RES ERJ2GEJ 104 X (100 k)
B
99.6/10.1
R77
7030005050 S.RES ERJ2GEJ 103 X (10 k)
B 100.5/11.3
R84
7030007340 S.RES ERJ2GEJ 153 X (15 k)
T
78.3/22.8
R85
7030007340 S.RES ERJ2GEJ 153 X (15 k)
T
77.1/23.2
R86
7030005050 S.RES ERJ2GEJ 103 X (10 k)
B
88.1/12.4
R87
7030004980 S.RES ERJ2GEJ 101 X (100)
B
90.5/12.4
R88
7030005580 S.RES ERJ2GEJ 560 X (56)
B
63.7/16
R89
7030007270 S.RES ERJ2GEJ 151 X (150)
T
88.4/17.9
R90
7030007270 S.RES ERJ2GEJ 151 X (150)
T
89.3/17
R91
7030007270 S.RES ERJ2GEJ 151 X (150)
T
88.8/28.3
R92
7030005050 S.RES ERJ2GEJ 103 X (10 k)
T
85.5/20.3
R93
7030007280 S.RES ERJ2GEJ 331 X (330)
T
91.5/17.8
R94
7030005050 S.RES ERJ2GEJ 103 X (10 k)
T
88/15.6
R95
7030005110 S.RES ERJ2GEJ 224 X (220 k)
B
80.8/26.2
R96
7030007280 S.RES ERJ2GEJ 331 X (330)
T
90.2/17
R97
7030007280 S.RES ERJ2GEJ 331 X (330)
B
88.4/28.1
R99
7030005530 S.RES ERJ2GEJ 100 X (10)
B
77.2/27.8
R100
7030005090 S.RES ERJ2GEJ 104 X (100 k)
T
81.7/33.5
R101
7030008400 S.RES ERJ2GEJ 182 X (1.8 k)
T
82.6/33.5
R102
7030007270 S.RES ERJ2GEJ 151 X (150)
B
74.1/28.7
R103
7030004970 S.RES ERJ2GEJ 470 X (47)
B
75.7/28.7
R104
7030005600 S.RES ERJ2GEJ 273 X (27 k)
B
70.2/33.2
R105
7030007300 S.RES ERJ2GEJ 332 X (3.3 k)
T
69.9/35.8
R106
7030009320 S.RES ERJ2GEJ 4R7 X (4.7)
T
69.1/34.6
R107
7030005210 S.RES ERJ2GEJ 822 X (8.2 k)
T
71.6/37.5
R108
7030005210 S.RES ERJ2GEJ 822 X (8.2 k)
T
72.3/34.6
R109
7030007060 S.RES ERJ2GEJ 684X (680 k)
B
64.8/29.4
R110
7030007570 S.RES ERJ2GEJ 122 X (1.2 k)
B
66.6/32.3
R111
7030005600 S.RES ERJ2GEJ 273 X (27 k)
T
70.9/41.5
R112
7030005000 S.RES ERJ2GEJ 471 X (470)
B
79.9/36.3
R113
7030005050 S.RES ERJ2GEJ 103 X (10 k)
B
48/17.9
R114
7030005090 S.RES ERJ2GEJ 104 X (100 k)
T
86.8/15.4
R115
7030005600 S.RES ERJ2GEJ 273 X (27 k)
T
89.7/11.8
R116
7030007300 S.RES ERJ2GEJ 332 X (3.3 k)
T
88/14
R117
7030007300 S.RES ERJ2GEJ 332 X (3.3 k)
T
88/13.1
R118
7030007300 S.RES ERJ2GEJ 332 X (3.3 k)
B
86.3/26
R119
7030007300 S.RES ERJ2GEJ 332 X (3.3 k)
T
85.8/26.2
R120
7030005600 S.RES ERJ2GEJ 273 X (27 k)
B
83.6/25.4
R121
7030005090 S.RES ERJ2GEJ 104 X (100 k)
B
72.2/35
R122
7030005000 S.RES ERJ2GEJ 471 X (470)
B
75/36.6
R123
7030005100 S.RES ERJ2GEJ 154 X (150 k)
B
73.2/38.2
R124
7030005040 S.RES ERJ2GEJ 472 X (4.7 k)
B
74.1/38.2
R125
7030005240 S.RES ERJ2GEJ 473 X (47 k)
B
53.4/9.1
R126
7030005060 S.RES ERJ2GEJ 333 X (33 k)
B
35.7/8.9
R128
7030005160 S.RES ERJ2GEJ 105 X (1 M)
B
46.2/34.5
R130
7030007570 S.RES ERJ2GEJ 122 X (1.2 k)
B
61.3/36.8
R131
7030005090 S.RES ERJ2GEJ 104 X (100 k)
B
63.6/38.1
R132
7030005070 S.RES ERJ2GEJ 683 X (68 k)
B
62/38.1
R133
7030007300 S.RES ERJ2GEJ 332 X (3.3 k)
B
65.2/36.3
R134
7030007340 S.RES ERJ2GEJ 153 X (15 k)
B
64.1/34.5
R135
7030005050 S.RES ERJ2GEJ 103 X (10 k)
B
62.5/34.5
R136
7030005040 S.RES ERJ2GEJ 472 X (4.7 k)
B
60.9/34.5
R137
7030005220 S.RES ERJ2GEJ 223 X (22 k)
B
66.1/36.9
R138
7030005220 S.RES ERJ2GEJ 223 X (22 k)
B
66.8/38.1
R139
7030005220 S.RES ERJ2GEJ 223 X (22 k)
B
67.3/36.9
R140
7030011660 S.RES ERJ2RKF 1002 (10 k)
B
57.4/40.2
R141
7030011670 S.RES ERJ2RKF 3902 (39 k)
B
57.7/41.4
R142
7030011660 S.RES ERJ2RKF 1002 (10 k)
B
56.5/38.3
R143
7030011670 S.RES ERJ2RKF 3902 (39 k)
T
54.4/37.7
R144
7030005120 S.RES ERJ2GEJ 102 X (1 k)
B
45.8/38
R145
7030007300 S.RES ERJ2GEJ 332 X (3.3 k)
T
46.9/31.2
R146 7030010040
S.RES
ERJ2GEJ-JPW
T
44.2/29.1
R147
7030005230 S.RES ERJ2GEJ 334 X (330 k)
T
55.6/39.3
R148
7030005060 S.RES ERJ2GEJ 333 X (33 k)
T
55.6/38.4
R149
7030005600 S.RES ERJ2GEJ 273 X (27 k)
T
56.2/37.2
R150
7030005000 S.RES ERJ2GEJ 471 X (470)
B
33.3/7.4
R151
7030005000 S.RES ERJ2GEJ 471 X (470)
T
45.9/19.2
R152
7030005160 S.RES ERJ2GEJ 105 X (1 M)
B
46.2/36.8
R153
7030005070 S.RES ERJ2GEJ 683 X (68 k)
T
45.7/35.8
R154
7030005090 S.RES ERJ2GEJ 104 X (100 k)
T
44.5/36.2
R155
7030005090 S.RES ERJ2GEJ 104 X (100 k)
B
45.3/4.4
R156
7030005210 S.RES ERJ2GEJ 822 X (8.2 k)
B
52.5/6.5
R157
7030005240 S.RES ERJ2GEJ 473 X (47 k)
B
54.3/9.7
R158
7030005060 S.RES ERJ2GEJ 333 X (33 k)
B
45/39.8
R159
7030005090 S.RES ERJ2GEJ 104 X (100 k)
B
45/38.9
R161 7030010040
S.RES
ERJ2GEJ-JPW
B 38/29.3
R164
7030005230 S.RES ERJ2GEJ 334 X (330 k)
B
37.1/29.3
R165
7030005080 S.RES ERJ2GEJ 823 X (82 k)
B
38/30.9
[MAIN UNIT]
REF
ORDER
DESCRIPTION
M.
H/V
NO.
NO.
LOCATION
R166
7030005040 S.RES ERJ2GEJ 472 X (4.7 k)
B
38.1/6.4
R167
7030005220 S.RES ERJ2GEJ 223 X (22 k)
B
36.5/5.5
R168
7030007290 S.RES ERJ2GEJ 222 X (2.2 k)
B
49.1/30.2
R169
7030011650 S.RES ERJ2GEJ 243X (24 k)
B
46.9/31.1
R170
7030005530 S.RES ERJ2GEJ 100 X (10)
T
53.2/25.8
R171
7030005160 S.RES ERJ2GEJ 105 X (1 M)
T
55.7/20.5
R173
7030005090 S.RES ERJ2GEJ 104 X (100 k)
B
60.4/31.8
R174
7030009140 S.RES ERJ2GEJ 272 X (2.7 k)
T
51.6/25.8
R175
7030009270 S.RES ERJ2GEJ 821 X (820)
T
52.1/27.4
R176
7030005090 S.RES ERJ2GEJ 104 X (100 k)
B
45.7/11.9
R177
7030005240 S.RES ERJ2GEJ 473 X (47 k)
B
53.4/10.7
R178
7030005070 S.RES ERJ2GEJ 683 X (68 k)
B
38.4/33.5
R179
7030005070 S.RES ERJ2GEJ 683 X (68 k)
T
40.5/29.6
R180
7030008300 S.RES ERJ2GEJ 184 X (180 k)
B
40.2/33.5
R181
7030011680 S.RES ERJ2RKF 2703 (270 k)
T
22/35.5
R182 7030010040
S.RES
ERJ2GEJ-JPW
B
41.5/25.4
R183
7030007060 S.RES ERJ2GEJ 684X (680 k)
B
46.9/27.1
R184
7030009140 S.RES ERJ2GEJ 272 X (2.7 k)
B
47.8/28.3
R185
7030005230 S.RES ERJ2GEJ 334 X (330 k)
B
47.8/29.5
R186
7030007340 S.RES ERJ2GEJ 153 X (15 k)
B
48.3/25.5
R187
7030005050 S.RES ERJ2GEJ 103 X (10 k)
B
58.2/32.8
R188
7030005090 S.RES ERJ2GEJ 104 X (100 k)
B
61.5/30.5
R189 7030010040
S.RES
ERJ2GEJ-JPW
B
97.2/21.9
R190
7030005700 S.RES ERJ2GEJ 274 X (270 k)
B
99.1/17.8
R191
7030005090 S.RES ERJ2GEJ 104 X (100 k)
T
97.3/18.4
R192
7030005050 S.RES ERJ2GEJ 103 X (10 k)
T
95.4/24.3
R193
7030004980 S.RES ERJ2GEJ 101 X (100)
B
98.8/20.9
R194
7030007290 S.RES ERJ2GEJ 222 X (2.2 k)
B 101.7/24.3
R195
7030005050 S.RES ERJ2GEJ 103 X (10 k)
B
95.4/24.2
R196
7030005040 S.RES ERJ2GEJ 472 X (4.7 k)
B
94.2/24.6
R197
7030005050 S.RES ERJ2GEJ 103 X (10 k)
B
96.1/19.6
R198
7030005040 S.RES ERJ2GEJ 472 X (4.7 k)
B
94.8/19.2
R199
7030005050 S.RES ERJ2GEJ 103 X (10 k)
T
97.5/12
R200
7030005040 S.RES ERJ2GEJ 472 X (4.7 k)
T
98.7/11.5
R201
7030005090 S.RES ERJ2GEJ 104 X (100 k)
B
61.6/11.4
R202
7030005110 S.RES ERJ2GEJ 224 X (220 k)
B
60.1/24.5
R203
7030005000 S.RES ERJ2GEJ 471 X (470)
B
61.8/29.3
R204
7030008310 S.RES ERJ2GEJ 564 X (560 k)
B
35.8/14.8
R205
7030005040 S.RES ERJ2GEJ 472 X (4.7 k)
B
60.2/27.9
R206
7030005040 S.RES ERJ2GEJ 472 X (4.7 k)
B
27.9/33.7
R207
7030005240 S.RES ERJ2GEJ 473 X (47 k)
B
32.5/36.2
R208
7030005240 S.RES ERJ2GEJ 473 X (47 k)
B
26.3/32.8
R209
7030005240 S.RES ERJ2GEJ 473 X (47 k)
B
24.5/33.7
R210
7030005240 S.RES ERJ2GEJ 473 X (47 k)
B
22.6/34.3
R211
7030005700 S.RES ERJ2GEJ 274 X (270 k)
T
26.3/35.5
R212
7030005070 S.RES ERJ2GEJ 683 X (68 k)
B
22.1/36.8
R213
7030005070 S.RES ERJ2GEJ 683 X (68 k)
B
21.5/38
R214
7030005070 S.RES ERJ2GEJ 683 X (68 k)
B
22.4/41.3
R215
7030005070 S.RES ERJ2GEJ 683 X (68 k)
B
20.9/40.5
R216
7030005070 S.RES ERJ2GEJ 683 X (68 k)
B
20.6/38
R217
7030005080 S.RES ERJ2GEJ 823 X (82 k)
B
41.5/26.3
R219
7030004980 S.RES ERJ2GEJ 101 X (100)
T
18.2/29.2
R220
7030005720 S.RES ERJ2GEJ 563 X (56 k)
B
39.9/26.3
R221 7410001130
S.ARY
EXB28V102JX
B 32/18.4
R222 7410001130
S.ARY
EXB28V102JX
T
30.2/20.4
R223 7410001130
S.ARY
EXB28V102JX
B
30.2/16.6
R225 7410001130
S.ARY
EXB28V102JX
B
28.1/14.5
R226 7410001130
S.ARY
EXB28V102JX
B
26.3/12.6
R227 7410001130
S.ARY
EXB28V102JX
T
21.3/15.6
R228
7030005000 S.RES ERJ2GEJ 471 X (470)
T
104/35.2
R229
7030005050 S.RES ERJ2GEJ 103 X (10 k)
B
30.7/8.7
R230
7030005090 S.RES ERJ2GEJ 104 X (100 k)
B
30.7/7.5
R231
7030005050 S.RES ERJ2GEJ 103 X (10 k)
T
98.9/39.1
R232
7030005090 S.RES ERJ2GEJ 104 X (100 k)
T
15.1/26.5
R233 7410001140
S.ARY
EXB28V104JX
T
22.2/21.2
R234
7030005050 S.RES ERJ2GEJ 103 X (10 k)
T
16/26.5
R235 7410001130
S.ARY
EXB28V102JX
B
16.7/15.5
R236 7410001140
S.ARY
EXB28V104JX
T
24.1/19.5
R238
7030004980 S.RES ERJ2GEJ 101 X (100)
B
12.7/21.7
R240
7030005090 S.RES ERJ2GEJ 104 X (100 k)
T
37.5/24.8
R242 7410001130
S.ARY
EXB28V102JX
B
34.5/20.1
R243
7030005530 S.RES ERJ2GEJ 100 X (10)
T
7.7/28.7
R244
7030005160 S.RES ERJ2GEJ 105 X (1 M)
T
6.5/29.1
R245
7030008010 S.RES ERJ2GEJ 123 X (12 k)
B
16.2/32.3
R246
7030008010 S.RES ERJ2GEJ 123 X (12 k)
B
12.4/32.8
R247
7030008010 S.RES ERJ2GEJ 123 X (12 k)
B
11.1/28.5
R248
7030005120 S.RES ERJ2GEJ 102 X (1 k)
T
22.6/26.9
R249
7030005090 S.RES ERJ2GEJ 104 X (100 k)
T
21.4/24.4
R250
7030005090 S.RES ERJ2GEJ 104 X (100 k)
T
43.8/13.8
R251
7030005050 S.RES ERJ2GEJ 103 X (10 k)
T
27.6/33.2
R252
7030005050 S.RES ERJ2GEJ 103 X (10 k)
T
27.6/32.3
R253 7410001140
S.ARY
EXB28V104JX
T 29.4/28
R255 7410001130
S.ARY
EXB28V102JX
T
25.8/29.5
R257 7410001130
S.ARY
EXB28V102JX
B
31.3/28.6
R258 7410001140
S.ARY
EXB28V104JX
T
31.5/29.3
R259 7410001130
S.ARY
EXB28V102JX
B
33.1/26.8
R260 7030010040
S.RES
ERJ2GEJ-JPW
B
29.2/36.7
R261
7030005220 S.RES ERJ2GEJ 223 X (22 k)
T
26.3/34.6
R262
7030005050 S.RES ERJ2GEJ 103 X (10 k)
T
23.6/33.9
R263
7030008300 S.RES ERJ2GEJ 184 X (180 k)
T
25.7/23.6
R264
7030005720 S.RES ERJ2GEJ 563 X (56 k)
T
25.7/24.6
R265
7030005220 S.RES ERJ2GEJ 223 X (22 k)
T
25.7/25.6
R266
7030005120 S.RES ERJ2GEJ 102 X (1 k)
T
22.3/34.3
[L]=Low band [H]=High band
