3
Table of Contents
Introduction 4
Positioning the projector
5
Projector and Device Connector Guide 6
Computer connections 6
Video connections 6
Connecting a computer source 9
Required computer connections 9
Optional computer connections 9
Displaying a computer source image 10
Adjusting the image 11
Using the projector with Windows 98 for the first time 12
Connecting a video device 14
Video device connections 15
Composite video connection 15
S-video connection 15
Component video connection 16
VGA connection 16
Displaying video 17
Adjusting the image 17
Shutting down the projector 19
Troubleshooting your setup 19
Using the remote control 27
Using the audio 28
Using the keypad buttons 28
Optimizing computer images 29
Presentation features 29
Optimizing video images 30
Customizing the projector 30
Using the menus 31
Picture menu 32
Settings menu 35
Maintenance 38
Cleaning the Lens 38
Replacing the Projection Lamp 38
Cleaning the Lamp Housing Screens 40
Using the security lock 40
Appendix 41
Specifications 41
Accessories 41
Projected image size
43
Red LED Behavior and Projector Errors 43
If you are experienced in setting up projection systems, use the Quick Setup
card that was included. For complete details on connecting and operating
the projector, refer to this User’s Guide. Electronic versions of this User’s
Guide in multiple languages are available on the included CD and on our
website at www.infocus.com/service.
The website also has technical specifications (an interactive image size cal-
culator, laptop activation commands, connector pin outs, a glossary, the
product data sheet), a web store to buy accessories, and a page for online
registration.
Important Operating Considerations
Do not place the projector on a tablecloth or other soft coverings that may
block the front or back vents. Do not use a non-approved ceiling mount. In
the unlikely event of the bulb rupturing, thoroughly clean the area in front
of the projector and discard any edible items that may have been placed in
that area.
Do not place objects in
this area in front
2 ft (
.6m)
of the projector
