Connecting to a Novell NetWare 5.1 or 4.11 Server
Microsoft Windows 2000 Professional
Requirements
Operating System Windows 2000 Professional
Driver Version 5.22.03.0050 (Embedded in OS)
Driver File IBMTRP.SYS
Server OS NetWare 5.1 or 4.11 Server
Client OS Client v4.80 for Windows NT/2000
Procedure
1. With the HP Vectra turned off, install the network adapter into an available PCI
slot.
2. Connect the network cable to the newly installed network adapter.
3. Connect the WOL cable between the network adapter and the PC motherboard.
4. Power on the machine and boot to Windows.
5. Logon to Windows with administrator privileges.
6. Windows will silently detect (i.e. without any messages or prompts) the network
adapter as “IBM 16/4 Token-Ring PCI Adapter 2 with Wake on LAN” during start
up and automatically install its embedded driver.
7. From the Device Manager, under Network adapters, double-click on “IBM 16/4
Token-Ring PCI Adapter 2 with Wake on LAN” to open its Properties window.
Click on the “Power Management” tab and check “Allow this device to bring the
computer out of standby”.
8. Additional changes in the System or Local Area Connection properties, such as:
workgroup name, computer name, TCP/IP properties, etc. may be necessary.
Ask your Network Administrator for more information. After changes are made, a
restart may be necessary.
9. From the location of the “Novell Client v4.80 for Windows NT/2000” installation
files, execute “SETUPNW.EXE”.
10. Click on “Yes” to accept the “Novell Terms and Conditions”.
11. Select either “Typical” or “Custom” and click on “Install”. Typical Installation is
normally chosen. Select Custom Installation only if you are an administrator or an
advanced user. When prompted for options during installation, ask your Network
Administrator for more information.
