iHome iP71 User Manual
Page 5
Raise Volume Button
Lower Volume Button
iPod sync mode button
Power Button
Universal Dock
2
Controls and Indicators
Front Panel
Back Panel
Side Left
Speaker Panel
Left Speaker
Right Speaker
Left Speaker
Right Speaker
Power LED
Stand
iPod sync on
USB Jack
Aux-in Jack
To Computer
audio Jack
DC Jack
Right Speaker Jack
To left
speaker Jack
