2Q 1999 North America – Networking Products
IBM 16/4 Token Ring
PCI Special NIC
E
A S E O F
U
S E
(continued)
MAC Address Labels
IBM 16/4 Token Ring PCI Special NIC has a MAC address label on the outside of the bracket to make network
troubleshooting easier.
Conformance to Industry Standards
The IBM 16/4 Token Ring PCI Special NIC is fully compatible with Windows NT and Microsoft’s PC98/PC99
networking standards. Additionally, the IBM 16/4 Token Ring PCI Special NIC is Novell NetWare certified.
Warranty
1
Compaq supports this product with a limited lifetime warranty
1
. Technical support is available at your fingertips 24
hours a day, 7 days a week.
S
P E C I F I C A T I O N S
Compliance
Basic Token Ring (IEEE 802.5)
Dedicated Token Ring (IEEE 802.5R)
PCI 2.2 and 2.1
General Specifications
Wake on LAN (WOL)
16/4 Mbps
16K transmit & 4K receive buffer memory
PCI Hot Plug for Novell NetWare
5V
DTR for full-duplex support
Bus mastering
Boot ROM socket
UTP/STP support with RJ-45 and DB9 ports
Operating System Support
Windows NT 4.0
Windows NT 3.51
Novell NetWare 5.x Server
Novell NetWare 4.x Server
Novell NetWare 3.x Server
SCO UnixWare 7.x
SCO OpenServer 5.x
Microsoft Windows 98
Microsoft Windows 95
Microsoft Windows for Workgroups 3.11
NetWare DOS Client
MS DOS Client
OS/2 Warp 4
