Congratulations on your purchase of an Ikelite Digital Camera
Housing Ikelite has over years of experience in the underwater
photographic and lighting market Our products are designed and
built in the USA by Ikelite for both the professional and amateur
photographer
The clear housing permits instant visual inspection of the camera
and all sealing surfaces as well as complete monitoring of controls
and camera LCD screens
Ikelite Digital Housings are slightly negative in salt water for
stability This housing has been water pressure tested at the
factory Housing is pressure tested to ’ ( m)
Ikelite Digital Housing
i n s t r u c t i o n m a n u a l
#6132.35 for Olympus SP-350
2
Shutter
Release
Disp/
Guide
OK/Menu
Power
Flash/Erase
AEL
Arrow Pad
Shutter
Release
Lid
Snap
Lid
Snap
Mode
Zoom
Tray
Push
Button
Rubber
Handle
FRONT VIEW
BACK VIEW
External TTL
Strobe Connection
Lens Port
Quick View
3
LLuubbrriiccaannttss
Ikelite provides silicone lubricant with the housing We recommend
you use only Ikelite lubricant on Ikelite products as some other
brands may cause the o’ring to swell and not seal properly
Use only enough lubricant to lightly cover control shafts and
o’rings Wipe off any excess lubricant with a clean cloth
Lubricant is not a sealant it is used to reduce friction Excessive
lubricant can collect sand and dirt which may interfere with
proper sealing
CCAAU UTTIIO ON N
N Neevveerr uussee sspprraayy lluubbrriiccaannttss aass tthhee pprrooppeellllaanntt iinnggrreeddiieenntt ccaann
ccaauussee tthhee ppllaassttiicc hhoouussiinngg ttoo ccrraacckk
O Oppeenniinngg tthhee H Hoouussiinngg
Lid Snaps have a LLoocckk
To open push Lid Snap Lock
forward and lift as shown
Keep pressure on the Lid
Snap so it does not fly open
quickly
Some lid snaps have a lot of
spring tension once they go over center have a firm grip on the
lid snap Lid Snaps may be opened one at a time
Lift
Push Forward
Lid Snap Lock
4
IInnssttaalllliinngg tthhee CCaam meerraa
Remove the back from the housing The mounting tray for the
camera is secured to the housing back Position the camera on
the tray and secure it with the mounting bolt which threads
into the camera’s tripod socket U Ussee aa ccooiinn oorr ffllaatt bbllaaddddeedd
ssccrreew wddrriivveerr ttoo ttiigghhtteenn tthhee m moouunnttiinngg bboolltt ssoo tthhee ccaam meerraa iiss ffllaatt
aaggaaiinnsstt tthhee ttrraayy
CCAAU UTTIIO ON N::
Some camera tripod
socket threads are
plastic The mounting
tray bolt is metal Do
not cross thread or
over tighten as you
may damage the
camera tripod socket
threads
Mounting
Bolt
Mounting
Tray
O'Ring
OLYMPUS
