Ikelite SA-100 User Manual
Page 2
8
U
Ussiinngg FFllaasshh
U
Ussiinngg tthhee CCaam
meerraa’’ss BBuuiilltt--iinn FFllaasshh..
If you do not have an external flash, the camera’s built-in flash
can be used. See Diffuser instructions ((PPaaggee #
#88)).
NOTE: The camera’s built-in flash cannot be used with optional
Wide-Angle lenses.
D
Diiffffuusseerr aanndd D
Deefflleeccttoorr IInnssttaallllaattiioonn
Housing shown with
Deflector installed.
Deflector
CClloossiinngg tthhee H
Hoouussiinngg
1. Place housing face down in your
lap or on flat surface.
2. Check to see that there is an
o-ring on the housing back and
that it is clean and in its proper
location.
3. Guide the back into the housing
front. The o-ring should touch the
housing all the way around. There
should be an even gap all the way
around between the housing and
the housing back.
4. Lift the lid snaps so they are
extended and place the lid
snap into the hook on the housing
back.
5. To close the housing, push
down on the lid snaps until
they snap into place . Lid
snaps on opposite sides of the
housing should be closed at the
same time. Be sure they are down
far enough to engage the lock.
D
Doouubbllee cchheecckk - Once the housing is closed, check the o-ring seal.
Check the gap between the housing back and the housing. It
should be even all the way around the housing.
Look through the clear plastic back at the o-ring. You should see
a darkened area where the o-ring is compressed against the
housing back. If you do not see an even black compression seal
all the way around the back, open the lid snaps, reseat the
housing back and close the lid snaps. Visually check the seal again.
o-ring
housing back
housing back
o-ring
even gap
all 4 sides
5
6
CChheecckkiinngg CCoonnttrroollss
Once the housing has been closed, make sure the housing
controls line up with the corresponding camera controls. If the
housing controls are misaligned slightly make sure the camera
hold down bolt has been tightened down firmly so the camera
is flat against the tray.
TTuurrnn CCaam
meerraa O
Onn
Turn the camera on and operate each of the housing controls to
get a feel for using the camera in the housing. Take a few pictures
above water with the camera in the housing.
LLuubbrriiccaannttss
1. Ikelite provides silicone lubricant with the housing. We recommend
you use only Ikelite lubricant on Ikelite products as some other
brands may cause the o-ring to swell and not seal properly.
2. Use only enough lubricant to lightly cover control shafts and
o-rings. Wipe off any excess lubricant with a clean cloth.
Lubricant is not a sealant, it is used to reduce friction. Excessive
lubricant can collect sand and dirt which may interfere with
proper sealing.
CCAAU
UTTIIO
ON
N
N
Neevveerr uussee sspprraayy lluubbrriiccaannttss aass tthhee pprrooppeellllaanntt iinnggrreeddiieenntt ccaann
c
caauussee tthhee ppllaassttiicc hhoouussiinngg ttoo ccrraacckk..
7
D
Diiffffuusseerr aanndd D
Deefflleeccttoorr ccoonntt..
A diffuser and deflector are
included with the housing. The
diffuser is white transparent
plastic. The deflector is also
white, but is not transparent.
To install the diffuser or
deflector, spread the port
clamp at the spring end and
slide over the lens port. The
white plastic should be placed
in front of the camera flash.
The port clamp should be
pushed back against the front
of the housing.
D
Diiffffuusseerr
The diffuser should be installed when using the camera’s built
in flash. When shooting with the camera’s built-in flash at
approximately 2 feet (0.6 m) or less, the lens port on the
housing may block a portion of the light from the camera’s
built-in flash, creating a shadow in the lower area of the photo.
If this occurs, zoom the lens slightly to eliminate the shadow.
(You can test this above water)
D
Deefflleeccttoorr
The deflector should be installed when using an external strobe
such as the DS51 or DS160 Substrobe and EV Controller. The
deflector will redirect the camera’s flash to the EV Controller
which controls the external strobes output.
Diffuser/Deflector material
Port Clamp
Spring
Spread to Install
