32
SPECIFICATIONS
New2001 New2001
13
D D GENERAL
• Frequency coverage : TX 156.025–157.425 MHz
RX 156.050–163.275 MHz
• Mode : 16K0G3E
• Power supply requirement : Specified Icom’s battery pack only
• Current drain (at 7.5 V DC; approx.) :
TX High (at 6 W) 1.7 A
TX Mid. (at 3 W) 1.3 A
TX Low (at 1 W) 0.7 A
RX Max. audio 400 mA (internal speaker)
200 mA (external speaker)
• Useable temperature range : –20°C to +60°C; –4°F to +140°F
• Frequency error : ±10 ppm
• Antenna connector : SMA (50 Ω nominal)
• Dimensions : 52.5(W) × 125(H) × 30(D) mm
(Projections not included) 2 1 ⁄ 16 (W) × 4 29 ⁄ 32 (H) × 1 3 ⁄ 16 (D) inch
• Weight (with BP-245) : Approx. 280 g (9.9 oz)
D D TRANSMITTER
• Output power (at 7.5 V DC) : 6 W* (High) , 3 W (Middle)
and 1 W (Low) *5 W for some versions
• Modulation system : Variable reactance frequency mod-
ulation
• Max. frequency deviation : ±5 kHz
• Adjacent channel power : 70 dB
• Spurious emissions : –68 dBc typical
D D RECEIVER
• Receive system : Double-conversion superhetero-
dyne
• Sensitivity (12 dB SINAD) : 0.22 µV typical
• Squelch sensitivity : 0.35 µV typical (at threshold)
• Intermodulation rejection ratio: 70 dB typical
• Spurious response rejection ratio:
70 dB typical
• Adjacent channel selectivity : 70 dB typical
• Audio output power :
Internal speaker 0.6 W typical at 10% distortion with an
8 Ω load
External speaker 0.35 W typical at 10% distortion with an
8 Ω load
All stated specifications are subject to change without notice or
obligation.
