28
OPTIONAL SWIVEL BELT CLIP
New2001
9
■ Attachment
q Screw the base clip to the
back of the transceiver
using the two screws
(sup-
plied) , as shown at right.
w Clip the belt clip over your belt and insert the transceiver.
e Once the transceiver is locked in place, it swivels.
■ Detachment
➥ Turn the transceiver upside down in the direction of the
arrow and pull out from the belt clip.
R R CAUTION!:
HOLD THE TRANSCEIVER TIGHTLY
WHEN HANGING OR DETACHING THE TRANSCEIVER
FROM THE BELT CLIP.
Otherwise the transceiver may not be attached to the belt
clip or swivelled properly if the transceiver is accidentally
dropped and the base clip is scratched or damaged.
Supplied screws
