Page 20
18
Manual Image Setup
Normally, you can complete the setup procedure using
A
UTO
I
MAGE
S
ETUP
;
however, if your screen image is still distorted after you perform
A
UTO
I
MAGE
S
ETUP
or the Installation CD does not run on your system, perform
M
ANUAL
I
MAGE
S
ETUP
.
If the monitor is in standby
mode (STANDBY ON), it
might automatically turn off while
you are waiting for it to warm up.
1.
Have your monitor turned on for about 15 minutes, until the monitor
warms up.
2.
Display the image you most frequently use on the screen.
3.
Press the OSD Enter button
at the bottom of the monitor to display
the initial OSD menu.
4.
Use an Arrow button (
or
) to select the Image Setup icon
and press the OSD Enter button
to access the function.
5.
Using an Arrow button (
or
), select
MANUAL
, press
and then
press
again to access the Clock function
(
see
page
22) .
6.
Use the Arrow buttons (
or
) to manually adjust the image (as
much as possible).
7.
Next press the
button to select Phase.
8.
Use the Arrow buttons (
or
), again to tune the image to your
liking. To save, press the
button two times.
9.
When finished, press the Exit button
to exit from the OSD.
You have completed the monitor manual image setup procedure.
