2.2. Assembly terms
Mounting plate
DEC Unit
DEC DIN cable
Polar Axis Cover
Main control box
Polar Scope Cover
Lat. Locking Screw
Azi. Adjust. Knob
8406 Hand Controller
Azi. Locking Screw
CW Shaft
Counterweight (CW)
CW Safety Screw
R.A. Unit
Alignment Peg
Tripod Head
Tripod Lock
Tripod Spreader
Tripod Leg
Leg Lock Screw
Figure 5. iEQ75-GT assembly terms (mount and optional tripod)
