Ice-O-Matic VRC - Manual (Page 7)

Remote Condenser General Information
Page 1
Condenser Dimensions (Inches)
Model
Length Width Height Compatible With:
VRC1001 29.18 29.50 38.90 ICE0500R4
VRC1061 29.18 29.50 38.90 ICE0605/6R4, EMF1106R2
VRC2061 29.18 29.50 38.90 ICE0805/6/R3, ICE1005/6/7R3,
EMF2306R2
VRC2661
29.18 29.50 38.90 ICE1405/6/7R3, ICE1506R3
VRC5061 37.78 29.50 38.76 ICE1806/7R3, ICE2106/7R3
VRC Condenser
Note the warning symbol where it appears in this manual.
It is an alert for important safety information on a hazard that might cause serious injury.
Keep this manual for future reference.
Verify the ICE machine is compatible with the remote condenser. Some ice machines and some
remote condensers may or may not have a Mixing Valve (Head Master). Only one valve is required
per system. Kits are available to modify the remote condenser for compatibility. For more
information contact your Ice-O-Matic Distributor.
