Remote Condenser Service Parts
Page 10
Item Description VRC1001 VRC1061 VRC2061 VRC2661 VRC5061
1 Fan Guard 9131452-01 9131452-01 9131452-01 9131452-01 9131460-01
2
Top Panel 3013222-01 3013222-01 3013222-01 3013222-01 3013303-01
3
¼-20 x 1/2 Screw 9031019-04 9031019-04 9031019-04 9031019-04 9031019-04
4
Fan Blade 9131451-01 9131451-01 9131451-01 9131451-01 9131461-01
5
Fan Motor 9161117-02 9161117-01 9161117-01 9161117-01 9161118-01
6
¼-20 x ¾ Cap Screw 9031001-02 9031001-02 9031001-02 9031001-02 9031001-02
7
Flat Washer 9031003-01 9031003-01 9031003-01 9031003-01 9031003-01
8
Flanged Lock Nut 9031118-02 9031118-02 9031118-02 9031118-02 9031118-02
9
¼-20 x 1/2 Screw 9031019-04 9031019-04 9031019-04 9031019-04 9031019-04
10
Rear Panel 3013224-01 3013224-01 3013224-01 3013224-01 3013224-01
11
Brace 3013226-01 3013226-01 3013226-01 3013226-01 3013305-01
12
Leg 3013227-01 3013227-01 3013227-01 3013227-01 3013227-01
13
Leg Brace 3013228-01 3013228-01 3013228-01 3013228-01 3013306-01
14 T-Nut-Shipping Only
N/A N/A N/A N/A N/A
15
Brace 3013226-01 3013226-01 3013226-01 3013226-01 3013305-01
16
Cover Panel 3013232-01 3013232-01 N/A N/A N/A
17 Center Panel 3013225-01 3013225-01 3013225-01 3013225-01 3013304-01
18
Front Panel 3013223-01 3013223-01 3013223-01 3013223-01 3013223-01
19
Motor Brace 3013234-01 3013234-01 3013234-01 3013234-01 3013307-01
20 Motor
Brace Support 3013233-01 3013233-01 3013233-01 3013233-01 3013233-01
21 Junction
Box Cover 3013229-01 3013229-01 3013229-01 3013229-01 3013229-01
22
Mixing Valve 9151142-02 9151142-02 9151142-02 9151142-02 9151142-02
23
Condenser 9141130-01 9141130-01 9141130-01 9141131-01 9141133-01
24
Filter 9151143-01 9151143-01 9151143-01 9151143-01 9151143-01
25
1/2 Coupling 9091001-12 9091001-12 9091001-12 9091001-12 9091001-12
26
3/8 Coupling 9091001-11 9091001-11 9091001-11 9091001-11 9091001-11
27
Filter 9151143-02 9151143-02 9151143-02 9151143-02 9151143-02
