RAISED TOILET SEAT
MODEL NOS. 1391P (WITHOUT ARMS)
1391AP (WITH ARMS)
Assembly, Installation and Operating Instructions
SAVE THESE INSTRUCTIONS
NOTE: Check ALL parts for shipping damage. If ship-
ping damage is noted, DO NOT use. Contact Carrier/
Dealer for further instruction.
SAFETY SUMMARY
The following recommendations are made for the
safe installation of the Raised Toilet Seat:
WARNING
DO NOT install this equipment without first read-
ing and understanding this instruction sheet. If you
are unable to understand these Warnings, Cau-
tions and Instructions, contact a healthcare pro-
fessional, dealer or technical personnel if appli-
cable before attempting to install this equipment
- otherwise, injury or damage may occur.
Use the arm supports ONLY for assistance. DO
NOT attempt to use the arms to support full body
weight.
Always check to make sure that the Raised Toi-
let Seat is properly and securely locked in place
before using.
Make certain that the knob that secures the
Raised Toilet Seat to the commode is tight at all
times.
Center your weight on the Raised Toilet Seat.
The seat may tip if you lean too far forward or to
either side.
Users with limited physical capabilities should be
supervised or assisted when using the Raised Toi-
let Seat.
The Raised Toilet Seat has a weight limitation of
250 lbs. (114 kg.).
DO NOT Use Raised Toilet Seat if the toilet lip mea-
surement exceeds 1-3/4-inches (FIGURE 1). The
Raised Toilet Seat will not hold and may cause
injury.
DO NOT use tools. Hand tighten only. DO NOT
overtighten knob. The threads of the adjustment
bracket may strip. Check seat for proper installa-
tion and realign/retighten if necessary.
CAUTION
DO NOT FORCE knob as this may damage the
knob and/or the Raised Toilet Seat.
INSTALLING RAISED TOILET SEAT
(FIGURE 1)
NOTE: Refer to the WARNINGS and CAUTIONS in
the SAFETY SUMMARY of this instruction sheet.
1. Remove contents from the carton.
2. Rotate the knob on the front of the Raised Toilet
Seat counterclockwise enough so the adjustment
bracket will fit inside of the toilet bowl.
NOTE:The existing toilet seat/lid can either be removed
or flipped-up out of the way depending on usage of the
Raised Toilet Seat.
3. Place the Raised Toilet Seat on the toilet bowl.
T Toilet Bowl
Adjustment
Bracket
Seat Installed
Knob
Knob
1-3/4-inch
Toilet Lip
Rear Seat Wings
FIGURE 1-INSTALLING/REMOVING RAISED
TOILET SEAT
NOTE: The Raised Toilet Seat MUST be level, straight,
and the adjustment bracket MUST be inside the toilet
bowl. The rear seat wings MUST be positioned un-
der the rear lip of the toilet bowl (FIGURE 1).
4. After the Raised Toilet Seat is properly placed onto
the toilet, turn the knob clockwise until the adjust-
ment bracket is securely fastened to the front of the
toilet bowl.
