1 Part No. 1087196 SHOWER CHAIR
SAVE THESE INSTRUCTIONS
NOTE: Check ALL parts for shipping damage. If shipping damage is noted, DO NOT use. Contact Carrier/
Dealer for further instruction.
SAFETY SUMMARY
To ensure the safe installation of the Shower Chair, these instructions MUST
be followed:
GENERAL WARNINGS
DO NOT install this equipment without first reading and understanding this
instruction sheet. If you are unable to understand these Warnings, Cautions
and Instructions, contact a healthcare professional, dealer or technical
personnel if applicable before attempting to install this equipment - otherwise,
injury or damage may occur.
Ensure that the snap buttons fully protrude through the same respective
adjustment hole of each leg extension. This ensures that the adjustable legs are
securely locked in position and an even height adjustment is achieved.
Always inspect the Shower Chair to ensure that it is properly positioned and is
stable before using.
Ensure that ALL hardware is tight at ALL times.
Check rubber tips for rips, tears, cracks or wear. If any of these conditions
exist, replace rubber tips immediately.
Rubber tips MUST be in flush contact with the floor/tub floor at all times.
DO NOT use with tub floors less than 16-inches (40.64 cm) wide.
Users with limited physical capabilities should be supervised or assisted when
using the Shower Chair.
Ensure user weight is evenly distributed when seated. Improper loading may
result in shower chair tipping over.
For models with backrest, ensure the compression buttons on the backrest are
fully visible through notch on back of seat before using.
The Shower Chair has a weight limitation of 250 lbs (114 kg).
Shower Chair is NOT to be used as a transfer bench or transfer device.
ASSEMBLING THE SHOWER CHAIR (FIGURE 1)
NOTE: Refer to the WARNINGS in the SAFETY SUMMARY of this instruction sheet.
1. Remove contents from carton.
2. Place seat upside down on ground/floor.
3. Position top leg cutout over bottom leg cutout, as shown in FIGURE 1, aligning center
holes of each tube.
NOTE: Top leg must be positioned on top of bottom leg to ensure a proper and safe fit.
Shower Chair
Assembly, Installation and Operating Instructions
Model Nos. 9680P, 9680 (w/o Backrest), 9681P, 9681 (w/ Backrest)
