4 ◆ Compositions Overture OVTR 2/OVTR 3 – Owner’s Manual
S
TEREO
P
LACEMENT
...
Figure 3. Experiment with speaker
placement to obtain the best bass level
and stereo imaging in your room.
H
OME
T
HEATER
P
LACEMENT
...
P
LANNING
Y
OUR
S
YSTEM
Before deciding where to put your Compositions Overture speakers,
survey your room and think about placement, keeping the following
points in mind:
◆ For best results, try placing the speakers closer together than the
distance to the listening area.
◆ Refer to Figure 3 when placing speakers for best bass level and
stereo image (also see Operating The System on page 6).
Compositions Overture speakers are also suitable for use in
reproducing home theater sound from front left and right channels:
◆ Place one Compositions Overture speaker on the left and another on
the right, along either side of the television monitor.
◆ Since the speakers are magnetically shielded, you can set them in
very close without worrying about the field distorting the TV picture.
NOTE: For maximum home theater enjoyment, your audio system should also
include a center-channel speaker and a pair of rear-surround speakers.
Moreover, you can add a subwoofer for deep bass impact on sound effects and
music. Contact your local Infinity dealer for recommendations on adding these
home theater speakers to your system.
Listening Position
Left
Channel
Right
Channel
angle speakers
inward to
improve stereo
imaging
move speakers towards corners to increase bass
Overture 2/3 Ins 9/11/98 4:23 PM Page 4
