Features
This guide covers both the 16- and 24-port versions of the Intel
®
Express
410T Standalone Switch.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
Left
Link = Solid Green
Activity = Blinking Green
Collision = Blinking Orange
Right
10Mbps = Solid Orange
100Mbps = Off
MDI
MDI-X
Status
Intel
®
Express 410T Standalone Switch
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
Left
Link = Solid Green
Activity = Blinking Green
Collision = Blinking Orange
Right
10Mbps = Solid Orange
100Mbps = Off
MDI
MDI-X
Status
Intel
®
Express 410T Standalone Switch
Local Management
AC Input
100-240 VAC
50Hz-60Hz
1.0A max
Console: 9600-8-N-1
EIA 232
• Autonegotiates speed—10Mbps or 100Mbps
per port.
• Ports settings can be configured manually through Local Management.
• Enables flow control at half- and full-duplex.
Port
Port LEDs
16-port 410T Switch (Product Code ES410T16)
24-port 410T Switch (Product Code ES410T24)
AC Power
Plug
User Guide - Overview
Back of 16- and 24-port 410T Switch
Serial Port
MDI/MDI-X
button
Port
Port LEDs
MDI/MDI-X
button
