16
NS-27RTV 27-inch Color TV
www.insignia-products.com
To listen to a second audio program (SAP):
1 Press MENU, then press or to select the
AUDIO menu.
2 Press or to select MTS.
3 Press or to select SAP.
The television speakers output the second
audio program instead of normal audio.
Selecting the digital output
You can choose the format of the digital audio
output signal.
To select the digital output:
1 Press MENU, then press or to select the
AUDIO menu.
2 Press or to select DIGITAL OUTPUT.
3 Press or to select PCM or DOLBY
DIGITAL.
4 Press EXIT to return to the normal screen.
Selecting the audio language
When two or more audio languages are included
in a digital signal, you can select one of the
audio languages.
To select the audio language:
1 Press MENU, then press or to select the
AUDIO menu.
2 Press or to select AUDIO
LANGUAGE, then press or to display
the AUDIO LANGUAGE menu.
3 Press or to select your desired
language, then press ENTER.
4 Press EXIT to return to the normal screen.
Resetting your audio adjustments
The RESET function returns the audio
adjustments to the following factory settings:
To reset the audio adjustments:
1 Press MENU, then press or to select the
AUDIO menu.
2 Press or to select RESET, then press
.
Checking the digital signal strength
This television allows you to view the digital
signal meter for digital channels.
To check the digital signal strength:
1 Press MENU, then press or to select the
SETUP menu.
2 Press or to select SIGNAL METER.
3 Press or to check the digital-signal
strength.
4 Press EXIT to return to the normal screen.
Specifications
Design and specifications are subject to change
without notice.
Item Value
MTS STEREO
DIGITAL OUTPUT PCM
Note When you press RESET in the AUDIO
menu, the audio adjustments return to the
factory preset levels.
Note • The signal meter feature is not
available for analog channels.
• After four minutes, the SIGNAL
METER screen returns to normal
television-operation automatically.
Power supply AC 120V, 60 Hz
Power Consumption
Operation 110 Watts
Standby 3 Watts
Chassis Construction
Weight 80.5 lbs. (36.5 kg)
Width 25-9/16 inches (650 mm)
Height 22-1/2 inches (571.5 mm)
Depth 19-11/16 inches (500.5 mm)
Inputs
VIDEO 1 V (p-p)/75 ohms
AUDIO –8 dBm/50k ohms
S-VIDEO Y: 1 V (p-p), 75 ohms
C: 0.286 V (p-p), 75 ohms
COMPONENT Y: 1 V (p-p), 75 ohms
PR: 0.7 V (p-p), 75 ohms
PB: 0.7 V (p-p), 75 ohms
Output
DIGITAL AUDIO 0.5 V (p-p), 75 ohms
Other
Antenna input VHF/UHF In 75 ohm coaxial
Picture tube 27 inches (676.0 mm diagonal)
Tuner type Quartz PLL frequency
Receiving channels VHF 2-13
UHF 14-69
CABLE TV 14-36 (A)-(W)
37-59 (AA)-(WW)
60-85 (AAA)-(ZZZ)
86-94 (86)-(94)
95-99 (A-5)-(A-1)
100-125 (100)-(125)
01 (5A)
Speakers 2 inches (50.8 mm) x 3-1/2
inches (88.9 mm), 8 ohm x 2
Sound output power 1.0 W + 1.0 W
