PANEL DESCRIPTION
1
7
‘
‘
Function display
q
FUNCTION INDICATOR
Appears while a secondary function is being accessed.
w
SKIP CHANNEL INDICATOR
Appears when the selected memory channel is set as a “skip
channel.” (p. 32)
e
DUPLEX INDICATOR
Either “–” or “+” appears during repeater operation (p. 21).
r
TONE ENCODER INDICATOR
Appears when tone encoder is in use. (p. 21)
t
POCKET BEEP INDICATOR
Appears during pocket beep operation (p. 37).
y
TONE SQUELCH INDICATOR
Appears when tone squelch is in use. (p. 35)
u
DTCS INDICATOR
Appears when DTCS tone is in use. (p. 35)
i
TRANSMIT INDICATOR
Appears during transmit. (p. 18)
SKIP
AO
L
MR
F
TX
75
50
25
D
q
q
q
w
q
e
q
r
q
t
q
y
q
u
q
i
q
o
!5
!4
!3
q
!2
!0
!1
