Parts list – Ironman Fitness 220t User Manual
Page 24
Parts List
REF#
ITEM
DESCRIPTION
QTY
REF#
ITEM
DESCRIPTION
QTY
101 410-00023
ALLEN WRENCH
1
136 413-00004
POWER CORD
1
102 410-00024
ALLEN WRENCH
1
137 408-00016
TRANSFORMER (WITH FAN)
1
103 414-00023
DECAL SPEED, 150T, 220T, 320T
1
138 413-00018
FAN HARNESS
1
104 414-00024
DECAL ELEVATION, 150T, 220T, 320T
1
139 407-00007
MOTOR CONTROLLER, 08-0158
1
105 414-00028
DECAL CLEAR CONSOLE COVER,150T,220T,320T
1
140 407-00008
EKG MODULE, 07-0080
1
106 414-00025
DECAL IRONMAN UPRIGHTS
2
141 413-00019
TEL-LINE
1
108 414-00026
DECAL MODEL 220T
1
142 407-00006
SPEED INCLINE PCB, 07-0080
2
109 414-00027
DECAL IRONMAN DECK
1
143 414-00016
OVERLAY 150T
1
110 414-00002
SAFETY KEY DECAL
1
144 407-00010
CONSOLE PCB 5 WIN LED
1
112 410-00034
ZIP TIE, SMALL
4
145 408-00018
MEMBRANE SPEED
1
113 410-00035
ZIP TIE ,LARGE
15
146 408-00019
MEMBRANE INCLINE
1
114 402-00081
Plastic Washer
18
147 408-00020
MEMBRANE PROGRAM
1
115 402-00082
Washer 9*22*2
19
148 412-00005
ACTUATOR, 12-0045
1
116 402-00122
PHILLIP SCREW, ST4 X 13
4
149 415-00006
MANUAL 220T
1
117 402-00031
PHILIP SCREW ST4.2*13
31
150 402-00092
ALLEN BOLT
2
118 402-00085
Philip Screw 10-24"*12mm
1
151 406-00057
POWER CORD SPACER
1
119 408-00013
SPEED SENSOR
1
152 402-00093
GEAR WASHER
1
120 413-00012
ENCODER HARNESS
1
153 402-00098
PHILIP SCREW ST2.9*6.5
6
121 412-00006
MOTOR, 12-0049
1
155 406-00061
DECK BUMPER 41*3
2
122 406-00046
FAN (MOTOR)
1
156 402-00012
ALLEN BOLT M8*40
2
123 413-00013
CONSOLE HARNESS A
3pcs
157 402-00099
ALLEN BOLT M5*8
2
124 413-00014
SPEED AND INCLINE HARNESS
2
158 402-00100
PHILIP SCREW 4.2*25
4
125 413-00015
EKG HARNESS
2
160 406-00060
DECK BUMPER 25*19*16
1
126 408-00014
FUSE
2
162 406-00061
DECK BUMPER 41*3
2
127 408-00015
CIRCUIT BREAKER
1
163 402-00026
WASHER 9*16*1.6 (mm)
1
129 402-00087
SCREW
1
164 402-00123
PHILIP SCREW, ST4 X 25
2
130 402-00088
WASHER
1
165 402-00124
PHILIP SCREW, M6 X 10
2
131 407-00005
CONSOLE FAN MOTOR
1
166 402-00073
Washer 6.6x12x1.6mm
2
132 413-00016
REED SWITCH
1
167 406-00098
GROMMET IRONMAN UPRIGHT
1
133 413-00017
JUMPER WIRE
1
134 408-00017
MAGNET CORE
1
135 402-00089
WIRE CLIP
4
Ironman 220t Parts List Rev E
24
