Insignia NS-1DVDR - Manual (Page 27)

25
www.insignia-products.com
Specifications
General
Power requirements AC 120V, 60 Hz
Power consumption 18W
Dimensions (approx.) 16.9 Ч 2.13 Ч 10.83 in.
(w × h × d) (430 Ч 54 Ч 275 mm)
Mass (approx.) 5.73 lbs (2.6 kg)
Operating temperature 41°F to 95°F
(5°C to 35°C)
Operating humidity 5% to 90%
Signal system NTSC color system
Recording format NTSC
Recording
Recording format DVD VideoRecording,
DVD-VIDEO
Recordable discs DVD-ReWritable,
DVD-Recordable,
DVD+ReWritable,
DVD+Recordable
Recordable time
DVD (Approx.)
1 hr. (XP mode)
2 hr. (SP mode)
4 hr. (LP mode)
6 hr. (EP mode)
Video recording format
Sampling frequency 27 MHz
Compression format MPEG 2 (VBR
support)
Audio recording format
Sampling frequency 48 kHz
Compression format Dolby Digital
Playback
Frequency response DVD (PCM 48 kHz:
8 Hz to 22 kHz
CD: 8 Hz to 20 kHz
DVD (PCM 96 kHz):
8 Hz to 44 kHz
Signal-to-noise ratio >100 dB (AUDIO OUT
connector
Harmonic distortion <0.008% (AUDIO
OUT connector
Dynamic range >95 dB (AUDIO OUT
connector
Inputs
VIDEO INPUT 1.0 Vp-p 75 ohms,
sync negative,
RCA jack × 2
AUDIO INPUT 2.0 Vrms > 47 kohms
RCA jack (L, R) × 2
Outputs
VIDEO OUT 1 Vp-p 75 ohms, sync
neg., RCA jack × 1
COMPONENT VID. OUT (Y) 1.0 V (p-p),
75 ohms, neg. sync,
RCA jack × 1
(Pb)/(Pr) 0.7 V (p-p),
75 ohms,
RCA jack × 2
Audio output (digital) 0.5 V (p-p), 75 ohms,
RCA jack × 1
Audio output (analog) 2.0 Vrms (1 kHz,
0 dB), 600 ohms,
RCA jack (L, R) × 2
Accessories:
Video cable (1)
Audio cable (L, R)(1)
Remote Control (1)
Batteries (2)
Design and specifications are subject to change
without notice.
Legal notices
FCC compliance statement
This equipment has been tested and found to
comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable
protection against harmful interference when the
product is operated in a residential
installation.This equipment generates, uses, and
can radiate radio frequency energy and, if not
installed and used in accordance with the
instructions, may cause harmful interference to
radio communications. However, there is no
guarantee that interference will not occur in a
particular installation. Changes or modifications
to this equipment may cause harmful
interference unless the modifications are
expressly approved in the owner’s manual. The
user could lose the authority to operate this
equipment if an unauthorized change or
modification is made. If this equipment does
cause harmful interference to radio or television
reception, which can be determined by turning
the equipment off and on, the user is
encouraged to try to correct the interference by
one or more of the following measures:
•
Reorient or relocate the receiving antenna.
• Increase the separation between the
equipment and receiver.
• Connect the equipment into an outlet on a
circuit different from that to which the receiver
is connected.
• Consult the dealer or an experienced
radio/TV technician for help.
This device complies with Part 15 of the FCC
Rules. Operation is subject to the following two
conditions:
•
This device may not cause harmful
interference, and
• This device must accept any interference
received, including interference that may
cause undesired operation.
Copyright
© 2007 Insignia. Insignia and the Insignia logo are
trademarks of Best Buy Enterprise Services, Inc. Other
brands and product names are trademarks or
registered trademarks of their respective holders.
Specifications and features are subject to change
without notice or obligation.
