Figure 2. This example shows the
CC-2 center-channel speaker being
placed on top of a television in its
enclosed stand. The speaker can also
be placed on a shelf directly above
the set or below it and tilted up
(see Figure 3).
T
ILTING
T
HE
S
PEAKER
...
I
MPORTANT
!
Figure 3. The CC-2 center-channel
speaker can be tilted up or down in
its stand.
P
LACEMENT
The CC-2 center-channel speaker is designed for easy placement on top
of a television via the enclosed stand, as shown in Figure 2. If the top of
the television is not deep enough, place the CC-2 on a shelf directly
above it. Or place the speaker on a shelf below the set and tilt the CC-2
up in its stand towards listeners (refer to Figure 3).
If needed, the enclosed stand allows you to tilt the speaker across a
25-degree range (i.e., 18° up and 7° down), as shown in Figure 3.
DO NOT EXCEED THE TILT RANGE. Doing so may cause the speaker
to fall out of its stand.
CC-2
TV
Stand
CC-2 Tilt Range (Side View)
Tilt Down
(when on top of TV)
do not exceed maximum
down tilt (when bottom
of grille touches bumper)
do not exceed maximum
up tilt (when top of
grille is level)
Tilt Up
(when below TV)
No Tilt
(normal use)
