4.14 99$P114PBCC…MM…ET
Description: Change the CAN configuration of the i-7540D
¾
Syntax: 99$P114PBCCCCCCCCMMMMMMMMET
99$P114 Command
character
P CAN specification
0 = 2.0A
1
=
2.0B
B
CAN Baud rate
CCCCCCCC
32 bits Acceptance Code Register (00000000~FFFFFFFF)
MMMMMMMM 32 bits Acceptance Mask Register (00000000~FFFFFFFF)
E
Error response or not
0
=
Disable
1
=
Enable
T
Timestamp response or not
0
=
Disable
1
=
Enable
CAN baud rate list
B Description
0
10K baud rate of CAN
1
20K baud rate of CAN
2
50K baud rate of CAN
3
100K baud rate of CAN
4
125K baud rate of CAN
5
250K baud rate of CAN
6
500K baud rate of CAN
7
800K baud rate of CAN
8
1000K baud rate of CAN
9 User
defined
¾
Response:
Valid Command: OK
Invalid command: ERROR
