Parts List
1. Outlet Top
2. Pump Motor
3. Drive Motor
4. Handle Lock Mechanism
5. Pulley Assembly
6. Drive Belt
7. Drive Track
8. Body Assembly
9
. Filter Screen
10. Side Plate
11. PVA Brush
12. Filter Bag
13. Bottom Lid Assembly
14. Handle Assembly
15. Cable Assembly
16. Power Supply (Transformer)
1 .
17. Transformer Socket
8 Wheel Tube Assembly
19. OFF button
20. Light
21. ON button
22. Power Cord (Outlet)
23. Vacuum Intake Flaps
24. Lock Tabs
