Cisco MDS 9506 for IBM System Storage at a glance

IBM product numbers

2054-E04—Cisco MDS 9506 for IBM System Storage includes dual Supervisor-2 cards,

dual 1900 W AC power supplies

All models include SAN-OS 3.0 firmware with Fabric Manager, VSAN and PortChannel

capabilities

FC 2208—8 Port IP Services Module (no optics)

FC 2210—SAN Extension over IP for 8 Port IP Services Module

FC 2214—Multiprotocol Services Module

FC 2216—FCIP Activation for Multiprotocol Services Module

FC 2400—Storage Services Module

FC 2404—4-port 10 Gbps Fibre Channel Switching Module (no optics)

FC 2412—12-port 4 Gbps Fibre Channel Switching Module (no optics)

FC 2424—24-port 4 Gbps Fibre Channel Switching Module (no optics)

FC 2448—48-port 4 Gbps Fibre Channel Switching Module (no optics)

FC 5040—Fibre Channel 10 Gbps longwave X2 transceiver

FC 5210—Tri-Rate SW SPF Transceiver ( 1 and 2 Gbps FC and Gig Ethernet)

FC 5220—Tri-Rate LW SPF Transceiver ( 1 and 2 Gbps FC and Gig Ethernet)

FC 5230—Fibre Channel port shortwave SFP transceiver

FC 5240—Fibre Channel port longwave SFP transceiver

FC 5250—Ethernet Copper GbE SFP Transceiver

FC 5434—Fibre Channel 4 Gbps shortwave SFP transceiver, 4 pack

FC 5444—Fibre Channel 4 Gbps longwave SFP transceiver, 4 Km, 4 pack

FC 5454—Fibre Channel 4 Gbps longwave SFP transceiver, 10 Km, 4 pack

FC 5811—Flash Memory Card

FC 7021—MDS 9000 Enterprise Package

FC 7026—MDS 9500 Fabric Manager Server Package

FC 7036—MDS 9500 Mainframe Package

FC 7040—Storage Services Enabler Package

Fiber optic cables:

Multimode, 50u fiber optical cables with SC and/or LC connectors are available

Base warranty

One year, 24x7, same day, on-site IBM warranty.

Supported systems

1

IBM System p™ and selected IBM RS/6000® servers; IBM System x™ and selected

IBM Netfinity® servers; other Intel® processor-based servers running the Linux®,

Microsoft® Windows NT® or Microsoft Windows® 2000 operating systems; selected Sun

and HP servers; IBM TotalStorage Enterprise Storage Server® (ESS); IBM System Storage

DS8000 Disk Systems; IBM System Storage DS6000™ Disk Systems; IBM System Storage

DS4000 Disk Systems; IBM TotalStorage 3590 and 3592 Tape Drives; IBM TotalStorage

3494 Tape Library; IBM 3532, 3583 and 3584 Tape Libraries; and other selected storage

systems
