Ironman Fitness Edge - Manual (Page 36)

36
Parts List
REF # PARTS # DESCRIPTION QTY REF # PARTS # DESCRIPTION QTY
1 423-00076 CROSS BAR, EDGE 1 70 419-00028 LINKAGE PLATE 50*16*10*1.5, ENVISION 2
2 423-00082 LEFT UPRIGHT, EDGE 1 71 410-00065 LATCH SET, EDGE 1
3 423-00081 RIGHT UPRIGHT, EDGE 1 72 419-00009 REED SWITCH PLATE 1
4 423-00080 DECK FRAME, EDGE 1 73 402-00198 SPRING WASHER, 20*12*3, ENVISION 10
5 423-00079 BASE FRAME, EDGE 1 75 402-00009 HEX BOLT M10*45 1
6 423-00078 ELEVATION FRAME, EDGE 1 76 402-00201 ALLEN BOLT, M8*70, ENVISION 2
7 423-00077 ELEVATION SUPPORT, EDGE 1 77 402-00128 ALLEN BOLT, M8*55 2
8 419-00033 LINKAGE PLATE, EDGE 2 78 402-00011 ALLEN BOLT M8*15 4
9 419-00032 LEFT HANDLE BAR, EDGE 1 79 402-00197 ALLEN BOLT, M8*20, ENVISION 2
10 419-00034 RIGHT HANDLE BAR, EDGE 1 80 402-00196 ALLEN BOLT M8*25, ENVISION 2
11 404-00002 POLY V-BELT 200J8(508J8) 1 81 402-00195 ALLEN BOLT, M8*30, ENVISION 2
12 403-00010 WALKING BOARD 20*60, ENVISION 1 82 402-00105 ALLEN BOLT M10*15 4
13 404-00003 WALK BELT, 20*56, IRONMAN LOGO 1 83 402-00106 CHAMFER BOLT M6*25 10
14 406-00072 FRONT WHEEL 2 84 402-00018 PHILIP SCREW M6*12 5
15 406-00044 REAR WHEEL 4 85 402-00194 PHILLIP SCREW, 5*12, ENVISION 12
16 406-00073 ELEVATION WHEEL 4 87 402-00067 PHILIP SCREW ST4.2*16 42
17 409-00016 FRONT ROLLER, EDGE 1 88 402-00192 PHILLIP SCREW, ST4.2*12, ENVISION 55
18 409-00015 REAR ROLLER, EDGE 1 89 402-00163 SCREW, THREAD FORMING PAN M4X12 4
19 406-00109 BUMPER, 4500T/5500T 10 90 402-00069 Philip Screw ST2.9x9.5 32
20 406-00079 BASE BUMPER, 28*25*13 6 91 402-00035 SCREW ST2.9*6.5 7
21 406-00045 ADJUST SUPPORT 2 92 402-00208 PHILIP SCREW, ST4.8*16, EDGE 2
22 406-00080 CORD SPACER 4 93 402-00023 NYLON LOCK NUT M10 6
23 413-00089 POWER CORD GOMETER, 19*2.2, EDGE 1 94 402-00021 NYLON LOCK NUT M8 8
24 406-00204 BUMPER, 127*69.6*40.2, ENVISION 2 95 402-00190 NYLON LOCK NUT, M5, ENVISION 4
25 406-00202 MOTOR COVER, 698*365*162, ENVISION 1 96 402-00108 JAM NUT M8 4
26 406-00236 FENDER LEFT OUTSIDE, 689*268*67, EDGE 1 97 402-00026 WASHER 9*16*1.6 (mm) 11
27 406-00233 FENDER LEFT INSIDE, 690*268*38, EDGE 1 98 402-00193 WASHER, 9*22*2, ENVISION 6
28 406-00237 FENDER RIGHT OUTSIDE, 689*268*67, EDGE 1 99 402-00188 WASHER, 11*23*2, ENVISION 4
29 406-00234 FENDER RIGHT INSIDE, 690*268*38, EDGE 1 100 402-00008 HEX BOLT M10*60 1
30 406-00231 HANDLE COVER, LIFT TOP INSIDE,203*111*53 1 101 402-00065 Screw ST4.8*16 6
31 406-00235 HANDLE COVER, RIGHT TOP INSIDE, 203*111* 1 102 402-00104 SHOULDER ALLEN BOLT M8*80 2
32 406-00215 HANDLE COVER, LEFT OUTSIDE,210*62 1 103 402-00076 Philip Screw ST4.2x9.6 3
33 406-00216 HANDLE COVER, RIGHT OUTSIDE, 210*62 1 104 402-00046 CLIP NUT 4
34 406-00217 HANDLE COVER, LEFT INSIDE, 209*142*52 1 105 402-00048 PAN SPRING WASHER 10*19*0.25 4
35 406-00229 HANDLE COVER, RIGHT INSIDE,209*142*52, E 1 106 402-00114 SHOULDER ALLEN BOLT M8*60 1
36 406-00218 END CAP LEFT OUTSIDE, 152*20 1 107 402-00034 ALLEN WRENCH 110*75*6 1
37 406-00219 END CAP LEFT TOP,155*154*110, EDGE 1 108 406-00214 POWER CORD, EDGE 1
38 406-00220 END CAP LEFT FRONT, 103*77*44 1 109 413-00092 ENCODER HARNESS, 6C*22#*760mm, EDGE 1
39 406-00232 END CAP LEFT REAR, 113*70*63, EDGE 2 110 413-00091 HANDLE PULSE HARNESS, 2C*1370mm*22 2
40 406-00228 END CAP RIGHT OUTSIDE, 152*20, EDGE 1 111 413-00090 MAIN HARNESS, 12C*3150mm*24, EDGE 1
41 406-00227 END CAP RIGHT TOP, 155*154*110, EDGE 1 112 413-00088 JUMP HARNESS, 1C*500mm*16, EDGE 3
42 406-00226 END CAP RIGHT FRONT, 103*77*44 1 113 413-00087 HARNESS FOR FAN, 4C*460mm*22, EDGE 1
43 406-00225 INSERT, 351*337*43.5, EDGE 1 114 413-00086 PULSE HARNESS, 4C*355mm*24, EDGE 1
44 406-00209 CONSOLE BOX TOP, 746*457.5*41.5, ENVISIO 1 115 407-00129 ENCODER, SX 4009-P1, EDGE 1
45 406-00224 CONSOLE BOX BOTTOM, 746*457.5*69, EDGE 1 116 412-00006 MOTOR, 12-0049 W/ FLYWHEEL ONLY 1
46 406-00223 FAN GRILL, 133*72, EDGE 1 117 408-00056 FUSE, 12A\250V, EDGE 1
47 406-00222 BOTTLE HOLDER LEFT, 189*129*99, EDGE 1 118 408-00055 FUSE, 15A\250V, EDGE 1
48 406-00221 BOTTLE HOLDER RIGHT, 189*129*99, EDGE 1 119 413-00093 REED SWITCH, 32mm*19mm*2C*900cm, EDGE 1
51 410-00067 PULSE RECEPTACLE PLATE, 187*52*36, EDGE 2 123 408-00054 CIRCUIT BRAKER, EDGE 1
52 414-00140 ANTI SKID PADS, EDGE 2 124 402-00209 SCREW, 8/32*9.4, EDGE 1
53 405-00024 SIDE BOARD, 84*33*1360, EDGE 2 125 402-00087 SCREW 8/32*16 1
54 406-00195 HANDLE COVER, SJ40*40*1.5, ENVISION 2 126 402-00207 GEAR WASHER,02-0033, EDGE 1
55 406-00194 FAN MOTOR MOUNT, 98.7*85.7*31.8, ENVISIO 1 127 406-00230 MOTOR FOR FAN, 12V\700mA, EDGE 1
56 407-00125 CONSOLE FAN, 100*21.5, ENVISION 1 128 408-00057 FERRITE, EDGE 6
57 410-00063 PULSE RECEPTACLE PLATE, 40*24*8, EDGE 4 129 408-00058 TRANSFORMER, 110V\12V\2A, EDGE 1
58 402-00210 SAFETY KEY, EDGE 1 130 407-00107 MOTOR CONTROLLER, 08-0158H HAI ZHEN 1
59 410-00062 SPRING PLATE, 60*15*1, ENVISION 4 131 407-00111 EKG MODULE, 07-0092H HAI ZHEN 1
60 402-00205 SMALL BALL, 10*9 ENVISION 2 132 407-00131 PCB, EDGE 1
61 402-00206 BIG BALL, 10*13 2 133 408-00059 PROGRAM BUTTON, 1.6mm*55mm*80mm, EDGE 1
62 406-00210 BRACKET CONTROLLER, ENVISION 2 134 408-00060 POWER BUTTON, 1.6mm*60mm*80mm, EDGE 1
63 419-00012 REAR WHEEL SHAFT 2 135 412-00030 ACTUATOR, R20 1
64 419-00031 STOPPER BRACKET, EDGE 1 136 412-00031 ACTUATOR FAN, EDGE 1
65 402-00103 METAL BUSHING 2 137 408-00061 FERRITE, 13.5*29.6, EDGE 4
66 419-00015 BOLT SHAFT A 2 138 407-00130 REMOTE PCB, 58mm*25mm*1.6mm, EDGE 2
67 419-00016 BOLT SHAFT B 2 139 410-00064 PLUG, 12*12*4.5, EDGE 1
68 419-00019 BELT GUIDE BRACKET, HT95T/4500T/5500T 2 # 402-00211 Bolt Pack 1
69 410-00066 SOFT DROP SHOCK, EDGE 1
EDGE PARTS LIST REV. A
