1 - 2
• UT-115 SPECIFICATIONS
M
GENERAL
• Usable temperature range
: –10˚C to +60˚C; +14˚F to +140˚F
• Power supply requirement
: 5.0 V DC
(4.5 V–8.5 V for AMBE IC VCC line)
• AF input level
: 1 V
p-p
typical
• Modulation output level
: 350 mV
p-p
typical
• Demodulation input level
: 500 mV
p-p
typical
• AF output level
: 750 mV
p-p
typical
• CODEC type
: AMBE
• Transfer speed
: 4.8 kbps
• Control signal input voltage
: 3.0 V–5.0 V for High
0 V for Low
• Control signal output voltage : Open collector for High
0 V for Low
• Current drain (at 5.0 V DC)
: 55 mA typical
• Dimentions
: 30(W)
×38(D) mm;
(projections not included)
1
3
⁄
16
(W)
×1
1
⁄
2
(D) inch
• Weight
: Approx. 6 g;
7
⁄
32
oz
(accessoreis not included)
• Connector
: AXN430C330
All stated specifications are subject to change without notice or obligation.
