Assembly
5
INSTRUCTIONS FOR ASSEMBLY:
Unpack the box in a clear area. Check to make sure all components are present and in good condition.
Do not dispose of the packing material until the assembly is completed. Tools have been provided for you
to use when assembling this product.
Locate the hardware pack and identify the following parts required for assembly.
Tools:
1. Allen Wrench, M5 and M6
2. Phillips Screw Driver
3. Wrench
Main Components:
1. Owner’s Manual
2. Main Frame
3. Front Stabilizer Assembly
4. Handlebar w/Pulse Assembly
5. Upper Handlebar Assembly, Left and Right
6. Handle bar Post
7. Tension Knob
8. Sleeve Assembly Left and Right
9. Pedal Tube Assembly Left and Right
10. Console Assembly
11. Rear Stabilizer Assembly
12. Pedals Left and Right
13. Plastic Bellows
Hardware:
1. M8 Cap Nut (28) - Qty. 4
2. Arc Washer, M8 * 15 (27) - Qty. 12
3. Carriage Bolt, M8 * 70 (26) - Qty. 4
4. Screw, Button Head , M8 * 15 (52) - Qty. 8
5. Washer, M6 * 13 (70) - Qty. 4
6. Nylon Locknut, M6 (71) - Qty. 4
7. Carriage Bolt, M6 * 40 (69) - Qty. 4
8
. Bolt, Hex Head, 3/8 * 45 (15) - Qty. 4
9. Washer, 10 * 26 * 2.0 (16) - Qty 4
10. End Cap, #19 (73) - Qty 6
11. End Cap #13 (83) - Qty 2
