Page 16
REF# KEYS PART#
DESCRIPTION
QTY.
REF# KEYS PART#
DESCRIPTION
QTY.
1
323-00320
MAIN FRAME, 120E
1
45 302-00711
SCREW, #45
2
2a 331-00075
BALL BEARINGS #2A
1set
46 302-00712
MAGNETIC SPRING#46
1
2b 331-00076
BALL BEARINGS #2B
1set
47 302-00704
CAP NUT, M8
1
3
302-01145
MAGNET, 12.5 * 5
1
48 304-00005
BELT, J6 440
1
4
311-00056
PULLEY 270MM, DCS & 120E
1
49 313-00056
SPEED SENSOR
1
5
330-00077
PULLEY AXLE DCV5.2EL/120e
1
50 313-00195
PULSE WIRE, 120E
2
6
302-00691
NYLON LOCK NUT, 1/2" * 20T
4
51 313-00023
EXTENSION WIRE #51
1
7
330-00078
CRANK DCV5.2EL/120e
2
52 302-00715
SCREW, M8X15#52
8
8
319-00200
U BRACKET FOR PEDAL TUBE, 120E
2
53 310-00084
RESISTANCE CABLE #53
1
9
331-00086
BEARING, GREASED, 15.8 X 22.2
4
54 310-00047
RESISTANCE KNOB DCV5.2EL/120e
1
10 319-00201
PEDAL TUBE, 120E
2
55 302-00716
SCREW #55
1
11 306-00197
PLASTIC SPACER #11 DCV5.2/120e
2
56 323-00325
PULSE HANDLEBAR ASSEMBLY, 120E
1
12 302-00728
IDLER WHEEL SPACER
1
57 307-00086
CONSOLE, 120E
1
13 311-00029
IDLER WHEEL ALL INNOFIT UNITS
1
58 306-00615
LEFT COVER, 120E
1
14 306-00461
PEDAL, DCV5.2EL/120e
2
59 306-00616
RIGHT COVER, 120E
1
15 302-00695
HEX HEAD BOLT, 3/8" X 45
4
60 310-00168
ADJUSTABLE KNOB DCV5.2EL/120e
2
16 302-00696
WASHER, 10 X 26 X2
8
61 302-01130
SCREW, M4*16
5
17 302-00697
NYLOCK NUT, 3/8"
7
62 302-00719
SCREW, M5X75#62
5
18 319-00118
PU WHEEL #18
2
63 306-00455
PLASTIC BELLOW, DCV5.2EL/120e
1
19 331-00011
BEARING 608ZZ
4
64L 323-00323
UPPER HANDLEBAR, LEFT, 120E
1
20 302-01186
SPACER, 8.5 X 12.7 X 10
6
64R 323-00324
UPPER HANDLEBAR, RIGHT, 120E
1
21 302-00699
WASHER, 8X19X1.5
9
65 328-00037
FOAM GRIP #65
2
22 302-00700
SCREW, 8X33.5
2
66 306-00456
BAR CAP, DCV5.2EL/120e
4
23 302-00701
HEX HEAD SCREW M6 #23
2
67L 306-00617
SLEEVE, LEFT, 120E
1
24 319-00202
FRONT STABILIZER, 120E
1
67R 306-00618
SLEEVE, RIGHT, 120E
1
25 319-00120
FRONT STABILIZER CAP #25
2
68 306-00199
PLASTIC NUT CAP DCV5.2E/H/120e
2
26 302-00702
CARRIAGE BOLT M8X70 #26
4
69 302-00720
CARRIAGE BOLT M6X40 #69
4
27 302-00703
ARC WASHER 8X19X1.5 #27
12
70 302-01122
WASHER 6*13*1 TRI-5.3E
4
28 302-00704
CAP NUT, M8
4
71 302-00722
NUT M6#71
4
29 323-00321
TUBE RAIL, 120E
1
72 302-00723
WASHER 13X26X2#72
8
30 306-00451
REAR STABILIZER CAP, DCV5.2EL/120e
2
73 302-00724
NYLON LOCK NUT, #19
6
31 306-00452
RAIL TUBE CAP, DCV5.2EL
2
74L 323-00326
CONNECT TUBE LEFT, 120E
1
32 302-00705
HEX HEAD BOLT 3/8 * 25
1
74R 323-00327
CONNECT TUBE RIGHT, 120E
1
33 306-00566
WHEEL, DCV5.2EL/120e
1
75 302-00032
BEARING, 12.7X25.1
8
34 331-00078
BEARING #34
3
76 302-00725
BEARING,10X15
4
35 330-00076
WHEEL AXLE DCV5.2EL/120e
1
77 302-01116
HEX HEAD BOLT, 3/8"*50
2
36 331-00079
BEARING, 8 * 13 * 7, #36
5
78 302-00727
NYLOCK NUT#78
1
37 302-00706
SPRING #37
1
79 319-00132
IDLER ARM DCV5.2EL/120e
1
38 323-00322
UPRIGHT POST, 50.8, 120E
1
80 319-00203
U BRACKET, CONNECT TUBE,120E
2
39 302-00707
NYLON LOCK NUT M8 #39
10
81 302-01104
HEX HEAD BOLT M8*40
2
40 302-00031
WHEEL SPACER DISCOVERY 5.2
1
82 302-01187
SCREW, M8 * 55
2
41 302-00708
BC NUT 3/8"#41
1
83 302-01094
NYLOCK NUT M8
2
42 302-00709
WASHER 10X19X1.5#42
1
84 315-00033
OWNER'S MANUAL, 120E
1
43 302-00710
NUT, #43
1
44 319-00121
MAGNETIC PLATE #44
1
Ironman 120E Ellipticall Parts List Rev A
Parts List
16
