Ikelite Olympus C-60 User Manual

Page 3

CChheecckkiinngg CCoonnttrroollss

Once the housing has been closed push the controls back into

place Make sure they line up with the camera’s controls

ZZoooom

m CCoonnttrrooll

(NOTE:) After you have used the

housing’s zoom control it must be

returned to the center position to

disengage If the housing zoom

control is pushing the zoom lever

in either direction you cannot

take a picture or access any other

function as the camera is

receiving a signal from the

engaged zoom control

TTuurrnn CCaam

meerraa O

Onn

Turn the camera on and operate each of the housing controls to

get a feel for using the camera in the housing Take a few

pictures above water with the camera in the housing

Zoom control
engaged

Zoom control
disengaged
(centered)

LLuubbrriiccaannttss

Ikelite provides silicone lubricant with the housing We recommend

you use only Ikelite lubricant on Ikelite products as some other

brands may cause the o’ring to swell and not seal properly

Use only enough lubricant to lightly cover control shafts and

o’rings Wipe off any excess lubricant with a clean cloth

Lubricant is not a sealant it is used to reduce friction Excessive

lubricant can collect sand and dirt which may interfere with

proper sealing

CCAAU

UTTIIO

Neevveerr uussee sspprraayy lluubbrriiccaannttss aass tthhee pprrooppeellllaanntt iinnggrreeddiieenntt ccaann

ccaauussee tthhee ppllaassttiicc hhoouussiinngg ttoo ccrraacckk

Diiffffuusseerr &

& D

Deefflleeccttoorr IInnssttaallllaattiioonn

Housing shown with

Diffuser installed

Diffuser

Diiffffuusseerr aanndd D

Deefflleeccttoorr ccoonntt

A diffuser and deflector are

included with the housing The

diffuser is white transparent

plastic The deflector is also

white but is not transparent

and has a decal on the front

To install the diffuser or

deflector spread the port

clamp at the spring end

and slide over the lens port

The white plastic should be

placed in front of the camera

flash The port clamp should be

pushed back against the front

of the housing

Diiffffuusseerr

The diffuser should be installed when using the camera’s built in

flash When shooting with the camera’s built in flash at

approximately feet (

m) or less the lens port on the

housing may block a portion of the light from the camera’s

built in flash creating a shadow in the lower left of the photo

If this occurs zoom the lens slightly to eliminate the shadow

(You can test this above water)

Deefflleeccttoorr

The deflector should be installed when using an external strobe

such as the DS or DS Substrobe and EV Controller The

deflector will redirect the camera’s flash to the EV Controller

which controls the external strobes output

Diffuser/
Deflector
material

Port Clamp

Spring

Spread to Install

This edge
against
housing
