Part No. 1123851

1

MPR Recline Mechanism Kit

MPR Recline Mechanism Kit - Model
6905A, 6907A, 6908A

Assembly, Installation and Operating Instructions

Kit No. 1124312, 1124313

SAVE THESE INSTRUCTIONS

NOTE: Check ALL parts for shipping damage. In case of shipping damage, DO NOT use. Contact
Carrier/Dealer for further instruction.

SAFETY SUMMARY

To ensure the safe installation, operation and use of the MPR Recline
Mechanism Kit, these instructions MUST be followed:

GENERAL WARNING

DO NOT install or use this equipment without first reading and understanding
these instructions. If you are unable to understand the Warnings, Cautions or
Instructions, contact a healthcare professional, dealer or technical personnel before
attempting to install this equipment - otherwise injury or damage may occur.

INSTALLATION WARNING

After ANY adjustments, repair or service and before use, make sure all attaching
hardware is tightened securely - otherwise injury or damage may occur.

Recline Mechanism Kit (Part No. 1124312) contains the following items:

DESCRIPTION

QUANTITY

Recline Mechanism (Left and Right)

1 Pair

Footrest Guard

2

Recline Mechanism Hardware Kit (Part No. 1124313) contains the following items:

DESCRIPTION

QUANTITY

Seat Mounting Bracket

2

Plug Button

4

1/4-20 x 1-1/2-inch Hex Head Screw

8

1/4-20 x 1-inch Hex Head Screw

8

1/4-20 x 1/2-inch Flange Head Screw

4

1/4-20 Locknut

10

REPLACING RECLINE MECHANISM (FIGURE 1)

1. Engage wheel locks.
2. Remove the tray from recliner. Refer to STORING/REMOVING THE TRAY in the

Owner’s Manual, part number 54000M107.

3. Extend the footrest of the recliner.

For more information regarding Invacare products, parts, and services,

please visit: www.invacare.co

m
