1. Plug your USB keyboard and USB mouse into their corresponding USB ports located on the KVM’s

front panel.

2. Plug your DVI monitor, microphone, and speaker cables into the Console ports located on the unit’s

rear panel (left-most section labeled “console”).

3. Using one of the included KVM cables, plug the DVI, USB, and Audio connectors into one of the CPU

ports on the KVM

4. Plug the other end of the KVM

cable to the respective ports on
the computer that is part of your
installation.

5. Plug the USB peripherals that

you want to be part of your KVM
setup into the rear USB hub
ports

11

Installation

Setup and Installation
