Parts List
29
REF ITEM DESCRIPTION QTY REF ITEM DESCRIPTION QTY
101 410-00016 BELT GUIDE BRACKET 2 135 408-00014 FUSE 2
102 406-00057 POWER CORD SPACER 1 136 408-00015 CIRCUIT BREAKER 1
103 406-00119 HANDLE CAP, 150T.1/220T.1/320T.1/INSPIRE 1 137 407-00005 CONSOLE FAN MOTOR 1
104 406-00079 BASE BUMPER, 28*25*13 2 138 413-00016 REED SWITCH 1
105 402-00082 WASHER 9*22*2 4 139 413-00017 JUMPER WIRE 1
106 402-00083 Spring Washer 10 4 140 408-00017 MAGNET CORE 1
107 402-00031 PHILIP SCREW ST4.2*13 3 141 413-00004 POWER CORD 1
108 402-00031 PHILIP SCREW ST4.2*13 20 142 408-00016 TRANSFORMER (WITH FAN) 1
109 402-00085 Philip Screw 10-24"*12mm 1 143 413-00018 FAN HARNESS 1
110 402-00100 PHILIP SCREW 4.2*25 2 144 407-00007 MOTOR CONTROLLER, 08-0158 1
111 402-00099 ALLEN BOLT M5*8 2 145 407-00019 EKG MODULE, 07-0093 1
112 402-00012 ALLEN BOLT M8*40 2 146 413-00019 TEL-LINE 1
113 402-00124 PHILIP SCREW, M6 X 10 2 147 407-00006 SPEED INCLINE PCB, 07-0080 2
115 414-00057 DECAL FOLD UP HANDLE, IN-116, INSPIRE 1 148 407-00025 CONSOLE PCB, 07-0094, INSPIRE 1
116 415-00026 OWNER'S MANUAL INSPIRE 1 149 412-00005 ACTUATOR, 12-0045 1
117 406-00061 DECK BUMPER 41*3 2 150 408-00032 MEMBRANE PROGRAM, IN-087 1
118 402-00088 WASHER 6 151 408-00033 MEMBRANE POWER, IN-090 1
119 402-00081 Plastic Washer 18 152 414-00048 DECAL HRC RECEIVER, 320T.1/INSPIRE 1
120 402-00093 GEAR WASHER 1 153 414-00050 DECAL SAFETY KEY, 14-0027 2
121 402-00098 PHILIP SCREW ST2.9*6.5 6 154 402-00086 PHILIP SCREW, 10-24 X 42.5 1
122 402-00031 PHILIP SCREW ST4.2*13 8 155 402-00087 SCREW 8/32*16 1
123 402-00123 PHILIP SCREW, ST4 X 25 2 156 402-00088 WASHER 1
124 410-00014 ALLEN WRENCH HANGER 1 157 414-00049 OVERLAY IN-085 1
125 410-00045 ALLEN WRENCH, 75*5 1 158 407-00022 CHEST STRAP, 07-0091 1
126 410-00023 ALLEN WRENCH 3/16" 1 159 406-00097 HRC RECEIVER HOUSING 75x57x16.8 1
127 410-00024 ALLEN WRENCH 7/32" 1 160 407-00020 HEARTBEAT RECEIVER, 07-0090 1
128 408-00013 SPEED SENSOR 1 162 414-00025 DECAL IRONMAN UPRIGHTS, IN-049 2
129 413-00021 SPD AND INCL HARNESS A 2 163 414-00053 DECAL SIDE PLATFORM, IN-0117, INSPIRE 2
130 412-00008 MOTOR,12-0057 1 164 414-00055 DECAL BODY FAT LOGO, IN-114, INSPIRE 2
131 406-00046 FAN (MOTOR) 1 165 414-00056 DECAL BODY FAT CHART, IN-115, INSPIRE 1
132 413-00013 CONSOLE HARNESS A 1 167 414-00030 DECAL SPEED, IN-044, 150T, 220T, 320T,IN 1
133 413-00014 SPEED AND INCLINE HARNESS 2 168 414-00024 DECAL ELEVATION, IN-045, 150T, 220T, 320 1
134 413-00015 EKG HARNESS 1 169 402-00146 FLATHEAD SCREW, ST4.2X16 4
Inspire Parts List Rev B
