Parts List
28
REF ITEM DESCRIPTION QTY REF ITEM DESCRIPTION QTY
1 423-00043 CROSS BAR, INSPIRE 1 51 410-00042 LATCH GUIDE, 150T.1/220/320/INSPIRE 1
2 406-00055 BASE BUMPER, 38*33*15 2 52 406-00044 REAR WHEEL 4
3 406-00056 LONG BUMPER, 43*35*45 2 53 402-00050 POWER METAL BUSHING 9
4 423-00042 LEFT UPRIGHT, 150T.1/320T.1/220T.1/INSPI 1 54 402-00046 CLIP NUT 8
5 423-00041 RIGHT UPRIGHT W/LATCH RECEPTACLE, 150T.1 1 55 406-00034 TRANSPORT WHEEL 2
6 423-00011 DECK FRAME 1 56 404-00004 POLY V-BELT, 190J8 1
7 423-00040 BASE FRAME SILVER, INSPIRE 1 57 404-00013 WALKBELT, 20X60 NW RHOMBUS BELT, INSPIRE 1
8 419-00007 ELEVATION FRAME 1 58 403-00005 WALK BOARD, TRIAD/INSPIRE 1
9 419-00008 MOTOR FRAME 1 59 406-00035 DECK BUMPER, 24*20 8
10 405-00013 SIDE BOARD, LEFT INSPIRE 1 60 406-00098 GROMMET IRONMAN UPRIGHT 4
11 405-00014 SIDE BOARD, RIGHT, INSPIRE 1 61 406-00045 ADJUST SUPPORT 2
12 419-00010 LINKAGE BRACKET 2 62 409-00003 FRONT ROLLER, 150T,220T,320T 1
13 419-00009 REED SWITCH PLATE 1 63 409-00004 REAR ROLLER, 150T,220T,320T 1
14 419-00011 SIDE MOTOR COVER BRACKET 2 64 410-00046 SOFT DROP SHOCK, 400N 1
15 402-00142 THREADED CAP, LATCH, 150T/220/320.1, INS 1 65 419-00012 REAR WHEEL SHAFT 4
16 402-00143 LATCH PIN, 150T.1/220T.1/320T.1 1 66 402-00051 SHOULDER ALLEN BOLT 1/4"-20*63.5 2
17 419-00024 LATCH GUIDE PLATE, 150T.1/220T.1/320T.1 1 67 402-00052 SHOULDER ALLEN BOLT 1/4"-20*28.5 2
18 402-00141 SPRING FOR LATCH, 150T.1/220T.1/320T.1 1 68 402-00053 SHOULDER ALLEN BOLT 5/16"-18*45 2
19 406-00036 MOTOR COVER 1 69 402-00054 Allen Bolt 5/16"-18*15 6
20 406-00120 LEFT FENDER, 150T.1 (3" LONGER) 1 70 402-00055 Allen Bolt 5/16"-18*70 2
21 406-00121 RIGHT FENDER, 150T.1 (3"LONGER) 1 71 402-00056 Carriage Bolt 5/16"-18*25.4 9
22 406-00039 LEFT END CAP, SILVER 1 72 402-00057 Carriage Bolt 5/16"-18*19 4
23 406-00040 RIGHT END CAP, SILVER 1 73 402-00058 Nylon Lock Nut 5/16"-18*8.9 9
24 406-00126 MOLDED REAR PAN, INSPIRE 1 74 402-00059 Hex Bolt 3/8"-16*45 1
25 406-00049 FRONT BOTTOM PAN 1 75 402-00060 Hex Bolt 3/8"-16*63.5 1
26 406-00050 REAR BOTTOM PAN 1 76 402-00096 ALLEN BOLT 3/8" -16X35 2
27 406-00124 BOTTOM SHEET, INSPIRE 1 77 402-00062 Nylon Lock Nut 3/8"-16*11.5 2
28 406-00053 MAIN CONSOLE BOX (A) 1 78 402-00063 Nylon Lock Nut 5/16"-18*8.9 1
29 406-00022 LEFT TOP HANDLE COVER 1 79 402-00047 JAM NUT 5/16"*18 4
30 406-00023 RIGHT TOP HANDLE COVER 1 80 402-00064 Screw ST4.2*32 2
31 406-00024 LEFT POCKET BOTTOM 1 81 402-00065 Screw ST4.8*16 2
32 406-00025 RIGHT POCKET BOTTOM 1 82 406-00059 SQUARE BUMPER, 40*28*6 2
33 406-00026 LEFT BOTTOM HANDLE COVER 1 83 402-00097 PHILIP SCREW ST4*16 19
34 406-00027 RIGHT BOTTOM HANDLE COVER 1 84 402-00068 Philip Screw ST4.2x16 72
35 406-00028 REED SWITCH TOP HOLDER 1 85 402-00069 Philip Screw ST2.9x9.5 15
36 406-00029 REED SWITCH BOTTOM HOLDER 1 86 402-00140 SPRING WASHER 6 8
37 406-00123 CONSOLE A INSERT FOR 5 WIN LCD, INSPIRE 1 87 402-00018 PHILIP SCREW M6*12 8
38 402-00090 KILL SWITCH MAGNET 1 88 402-00139 ALLEN SCREW M8X16 1
39 414-00014 ANTI-SKID PAD, IN-042 2 89 402-00073 Washer 6.6x12x1.6mm 14
40 406-00030 FAN GRILL 1 90 402-00026 Washer 9x16x1.6mm 23
41 406-00032 FAN MOTOR MOUNT 1 91 402-00075 Spring Washer 8mm 12
42 402-00091 PLASTIC WASHER 2 92 410-00020 PULSE RECEPTACLE PLATE - TOP 2
43 402-00049 CLIP NUT 3 93 410-00021 PULSE RECEPTACLE PLATE - BOTTOM 2
44 405-00004 T EXTRUSION 1 94 402-00076 Philip Screw ST4.2x9.6 6
45 405-00005 S EXTRUSION 2 95 402-00077 Philip Screw M2.5x6 2
46 406-00041 PLUG CALIBRATION HOLE 1 96 402-00078 Washer 2.5x5x0.5mm 2
47 406-00125 DOME END CAP, INSPIRE 2 97 402-00079 SPRING WASHER 2.5MM 2
48 406-00047 FAN (CONSOLE) 1 98 402-00080 Gear Washer D=2.5 2
49 406-00042 LEFT SIDEBOARD COVER 1 99 402-00048 PAN SPRING WASHER 10*19*0.25 6
50 406-00043 RIGHT SIDEBOARD COVER 1 100 402-00138 PHILLIP SCREW M4X16 4
Inspire Parts List Rev B
