iHome iH69 User Manual
Page 5
Raise Volume Button
Lower Volume Button
iPod sync mode Button
Power Button
USB Jack
Headphone Jack
Aux-in Jack
To Computer
audio Jack
To Right Speaker Jack
To Left
Speaker Jack
iPod Dock
2
Controls and Indicators
Front Panel
Back Panel
Side Left
Speaker Panel
Left Speaker
Right Speaker
Left Speaker
Right Speaker
Power LED
Stand
iPod sync on
DC 7.5V, 2.5A
DC Jack
