Icom IC-910H - Manual (Page 49)

[MAIN UNIT] [MAIN UNIT]
S.=Surface mount
L652 6150004210 COIL LS-480
L653 6150004170 COIL LS-476
L703 6150004880 S.COIL LS-513
L704 6150004880 S.COIL LS-513
L851 6150004200 COIL LS-479
L852 6150004210 COIL LS-480
L853 6150004170 COIL LS-476
L854 6200002040 S.COIL NL 252018T-101J
L951 6200002040 S.COIL NL 252018T-101J
L1561 6200002040 S.COIL NL 252018T-101J
L1562 6200002040 S.COIL NL 252018T-101J
L1563 6200002040 S.COIL NL 252018T-101J
L1564 6200002040 S.COIL NL 252018T-101J
L1565 6200002040 S.COIL NL 252018T-101J
L1571 6200002040 S.COIL NL 252018T-101J
L1572 6200002040 S.COIL NL 252018T-101J
L1575 6200002040 S.COIL NL 252018T-101J
L1581 6200002040 S.COIL NL 252018T-101J
L1582 6200003950 S.COIL HF50ACC 322513-T
L1583 6200002040 S.COIL NL 252018T-101J
L1584 6200003950 S.COIL HF50ACC 322513-T
L1585 6200002040 S.COIL NL 252018T-101J
L1586 6200003950 S.COIL HF50ACC 322513-T
L1587 6200002040 S.COIL NL 252018T-101J
L1851 6170000140 COIL LW-15
L1852 6200003950 S.COIL HF50ACC 322513-T
L1853 6200003950 S.COIL HF50ACC 322513-T
L1854 6200003950 S.COIL HF50ACC 322513-T
R1 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 k Ω)
R2 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
R3 7310002720 S.TRIMMER RV-148 (RH03A3AS3X0DA) 472
R4 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 k Ω)
R5 7510001160 S.THERMISTOR NTCCM1608 4LH 473KC
R6 7030003270 S.RESISTOR ERJ3GEYJ 390 V (39 Ω)
R7 7030003500 S.RESISTOR ERJ3GEYJ 332 V (3.3 k Ω)
R8 7030003620 S.RESISTOR ERJ3GEYJ 333 V (33 k Ω)
R9 7030003360 S.RESISTOR ERJ3GEYJ 221 V (220 Ω)
R10 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 k Ω)
R21 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 k Ω)
R22 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 k Ω)
R23 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 k Ω)
R24 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 k Ω)
R51 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 k Ω)
R52 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 k Ω)
R53 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 k Ω)
R54 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 k Ω)
R55 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 k Ω)
R56 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 k Ω)
R57 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 k Ω)
R58 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 k Ω)
R59 7030003510 S.RESISTOR ERJ3GEYJ 392 V (3.9 k Ω)
R60 7030003240 S.RESISTOR ERJ3GEYJ 220 V (22 Ω)
R61 7030003760 S.RESISTOR ERJ3GEYJ 474 V (470 k Ω)
R62 7510001250 S.THERMISTOR NTCCM1608 3NH 471KC
R63 7030003330 S.RESISTOR ERJ3GEYJ 121 V (120 Ω)
R64 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 k Ω)
R65 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 k Ω)
R66 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
R67 7030003530 S.RESISTOR ERJ3GEYJ 562 V (5.6 k Ω)
R68 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 k Ω)
R101 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 k Ω)
R102 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 k Ω)
R103 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
R104 7030003760 S.RESISTOR ERJ3GEYJ 474 V (470 k Ω)
R105 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 k Ω)
R106 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 k Ω)
R107 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
R108 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 k Ω)
R109 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 k Ω)
R110 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 k Ω)
R111 7030003530 S.RESISTOR ERJ3GEYJ 562 V (5.6 k Ω)
R112 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 k Ω)
R113 7030003340 S.RESISTOR ERJ3GEYJ 151 V (150 Ω)
R114 7030003280 S.RESISTOR ERJ3GEYJ 470 V (47 Ω)
R151 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 k Ω)
R152 7030003460 S.RESISTOR ERJ3GEYJ 152 V (1.5 k Ω)
R153 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
R154 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 k Ω)
R155 7030003430 S.RESISTOR ERJ3GEYJ 821 V (820 Ω)
R156 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
R157 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 k Ω)
R158 7030003460 S.RESISTOR ERJ3GEYJ 152 V (1.5 k Ω)
R159 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
R160 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 k Ω)
R161 7030003430 S.RESISTOR ERJ3GEYJ 821 V (820 Ω)
R162 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
R163 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 k Ω)
R164 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 k Ω)
R165 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 k Ω)
R166 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 k Ω)
R167 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 k Ω)
R168 7030003540 S.RESISTOR ERJ3GEYJ 682 V (6.8 k Ω)
R169 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 k Ω)
R202 7310002740 S.TRIMMER RV-150 (RH03A3A14X0FC) 103
R203 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 k Ω)
R205 7030005451 S.RESISTOR ERA3YED 153V
R206 7310004930 S.TRIMMER EVM-3YSX50 B22 (201)
R207 7030005451 S.RESISTOR ERA3YED 153V
R208 7030003380 S.RESISTOR ERJ3GEYJ 331 V (330 Ω)
R209 7030006461 S.RESISTOR ERA3YED 152V
R210 7030003460 S.RESISTOR ERJ3GEYJ 152 V (1.5 k Ω)
R211 7030007230 S.RESISTOR ERA3YED 102V
R212 7030007230 S.RESISTOR ERA3YED 102V
R213 7030003490 S.RESISTOR ERJ3GEYJ 272 V (2.7 k Ω)
R215 7310004780 S.TRIMMER EVM-3YSX50 B13 (102)
R216 7030007230 S.RESISTOR ERA3YED 102V
R217 7030003490 S.RESISTOR ERJ3GEYJ 272 V (2.7 k Ω)
R218 7030003550 S.RESISTOR ERJ3GEYJ 822 V (8.2 k Ω)
R219 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470 Ω)
R220 7030005871 S.RESISTOR ERA3YKD 104V
R221 7030005871 S.RESISTOR ERA3YKD 104V
R222 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 k Ω)
R251 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470 Ω)
R252 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470 Ω)
R253 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 k Ω)
R254 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 k Ω)
R255 7030003360 S.RESISTOR ERJ3GEYJ 221 V (220 Ω)
R256 7030003500 S.RESISTOR ERJ3GEYJ 332 V (3.3 k Ω)
R257 7030003460 S.RESISTOR ERJ3GEYJ 152 V (1.5 k Ω)
R258 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 k Ω)
R259 7030003610 S.RESISTOR ERJ3GEYJ 273 V (27 k Ω)
R260 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 k Ω)
R261 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 k Ω)
R262 7030003760 S.RESISTOR ERJ3GEYJ 474 V (470 k Ω)
R264 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 k Ω)
R265 7510001110 S.THERMISTOR NTCCM1608 4BH 153KC
R266 7030003610 S.RESISTOR ERJ3GEYJ 273 V (27 k Ω)
R267 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 k Ω)
R268 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 k Ω)
R269 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 k Ω)
R270 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 k Ω)
R271 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 k Ω)
R302 7030003840 S.RESISTOR ERJ3GEYJ 225 V (2.2 M Ω)
R303 7030004710 S.RESISTOR ERJ3GEYJ 475 V (4.7 M Ω)
R304 7030003810 S.RESISTOR ERJ3GEYJ 125 V (1.2 M Ω)
R305 7030004710 S.RESISTOR ERJ3GEYJ 475 V (4.7 M Ω)
R306 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470 Ω)
R307 7030003490 S.RESISTOR ERJ3GEYJ 272 V (2.7 k Ω)
R308 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 k Ω)
R309 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470 Ω)
R310 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 k Ω)
R311 7030003740 S.RESISTOR ERJ3GEYJ 334 V (330 k Ω)
R312 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 k Ω)
R313 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 k Ω)
R314 7030003780 S.RESISTOR ERJ3GEYJ 684 V (680 k Ω)
R315 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 k Ω)
R316 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 k Ω)
R317 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 k Ω)
R340 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 k Ω)
R341 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
R344 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 k Ω)
R345 7030003200 S.RESISTOR ERJ3GEYJ 100 V (10 Ω)
R346 7030003490 S.RESISTOR ERJ3GEYJ 272 V (2.7 k Ω)
R353 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470 Ω)
R355 7030003330 S.RESISTOR ERJ3GEYJ 121 V (120 Ω)
R356 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
R358 7510001110 S.THERMISTOR NTCCM1608 4BH 153KC
R359 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 k Ω)
R360 7310002600 S.TRIMMER RV-110 (RH03A3AS4X0AA) 473
R361 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 k Ω)
R362 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470 Ω)
R363 7030003330 S.RESISTOR ERJ3GEYJ 121 V (120 Ω)
6 - 10
REF ORDER
DESCRIPTION
NO. NO.
REF ORDER
DESCRIPTION
NO. NO.
