If you want to secure your HDD Adapter, do as follows; otherwise, go
to step 4.

a. Prick the security screw cap with the tip of a ball-point pen

1

,

and then use the hole to remove the cap.

Security screw cap

UltraslimBay device lock

1

b. Install a hex-head screw into the screw hole

3

.

3

4

Turn the computer right side up. Connect the AC Adapter and

cables; then power on the computer.

Note: To tighten the security screw (or to remove it), use a 2.5-mm Allen

wrench.

Part 1. Using the ThinkPad 600 UltraslimBay HDD Adapter

1-5
