IBM 20X - Manual (Page 11)

Loading a CD
1. Press the Eject button. The tray slides out of the drive.
2. Place the CD in the tray with the label facing up.
3. Close the tray by gently pushing the tray in until it latches.
Attention: Do not use force or insert foreign objects to open the CD tray. If
your tray does not open when you press the Eject button, see “Manually ejecting a
CD” for more information.
Manually ejecting a CD
If you press the Eject button and the tray does not slide out, turn off the computer and
straighten a large paper clip to form a tool, as shown in the illustration. The
straightened end must extend at least 45 mm (1.8 in.). Insert the extended end into the
manual-eject hole on the front of the drive. Push the paper clip until the tray opens.
Gently pull out the tray until you can remove the CD.
45 mm
1.8 in
Part 1: Installation and user’s guide 1-5
