NS-14FTV/NS-20FTV Color TV
www.insignia-products.com
Conexión a un dispositivo de vídeo estándar
Si su modelo tiene tomas de audio laterales, use la ilustración
siguiente para conectar un dispositivo de vídeo estándar a los tomas
laterales.
Amarillo
Blanco
Audífonos
Rojo
Amarillo
(a la salida de video)
Blanco
Rojo
(a la salida de audio)
Dispositivo que no
tiene S-Video
