Disassembly
2 - 4 Disassembly Steps
2.Disassembly
Disassembly Steps
The following lists the disassembly steps, and on which page to find the related information. PLEASE PERFORM THE
DISASSEMBLY STEPS IN THE ORDER INDICATED.
To remove the hard disk drive assembly:
1. Remove the hard disk drive assembly page 2 - 5
To remove the system memory:
1. Remove the system memory page 2 - 7
To remove the processor:
1. Remove the system memory page 2 - 7
2. Remove the processor page 2 - 9
To remove the modem:
1. Remove the modem page 2 - 11
To remove the WLAN module:
1. Remove the modem page 2 - 11
2. Remove the WLAN module page 2 - 12
To remove the TV Tuner module:
1. Remove the modem page 2 - 11
2. Remove the TV Tuner module page 2 - 13
To remove the Bluetooth module:
1. Remove the modem page 2 - 11
2. Remove the TV Tuner module page 2 - 13
3. Remove the bluetooth module page 2 - 14
To remove the LCD back cover:
1. Remove the system memory page 2 - 7
2. Remove the modem page 2 - 11
1. Remove the LCD back cover page 2 - 15
To remove the Optical Device:
1. Remove the system memory page 2 - 7
2. Remove the modem page 2 - 11
3. Remove the LCD back cover page 2 - 15
4. Remove the optical device page 2 - 17
